TAIAN Mini Wheel loader DY620 with low price
mini wheel loader
1.All models have separately four hydraulic wheel motor, they are real four wheel drive hydrostatic dive.
2.All machines adopts world famous Kubota/Perkins which guarantees the quality and meanwhile more powerful.
3.All the actions of the machine can be achieved by only joystick/levels, buttons and switches, reasonable arrangements of all the controls makes the operating biggest comfortable.
4.Thanks to the quick coupling system, you can change into different attachments in just one minute, which is very simple and convenient.
5.We always take customers’ any possible needs into consideration, there’s cigar-lights on each machine.
6.We equipped window hook for the closed cabin so that the window can be opened a bit and offer better ventilation
mini wheel loader
Front and optional rear hydraulic output together with the quick coupling system makes it the transformers of machinery. Our loaders can be used wherever needs a machine, farming, landscaping, construction, estate and property maintenance, etc.
Model |
DY620 |
Dimension (LxWxH) |
2195 mm*980 mm*2150 mm |
Max. reach(boom extended) |
2750mm |
Max. reach(boom retracted) |
2480mm |
Bucket capacity |
300L |
Rated loading capacity |
500kg-800kg |
Min. turning radius |
1980mm |
Turning angle |
400 |
Speed |
10 km/h |
Weight |
1100 kg |
Standard tire |
23X8.5-12 |
Tire pressure |
2.8 bar |
Oil tank capacity |
35L |
Pressure |
190bar |
Working oil flow |
33L/min |
Tracking oil flow |
50L/min |
Oil model(mineral oil) |
L-HL46 |
Fuel tank capacity |
18L |
Battery capacity |
55Ah |
Voltage |
12v |
Engine brand |
Chinese Changchai 3M78 |
Engine type |
3 cylinders, water cooling |
Rated power/speed |
16kw / 2800r/min |
OPTIONS OF ENGINE | |
Engine brand |
Yanmar 3TNV382A |
Engine type |
3 cylinders, water cooling |
Rated power/speed |
22.2KW / 3000r/min |
1.For the new machine, within determined limits, the manufacture guarantees for a period of 12 months after bought or 1000 working hours(whichever comes first).
2.The warranty includes repairation or replace the parts for free which were proved to be defective in origin by the technical department of the manufacture.
3.The repairation or replacement for the parts should not exceed the warranty period.
4.The warranty is valid on the condition of all the terms listed in the contract was observed.
If you are interested in this machine and need a quotation, Please contact with: Steven.
