Small Engine Loader, CE Mini Loader With Backhoe for Sale

Name: Small Engine Loader, CE Mini Loader With Backhoe for Sale
Brand: TAIAN
SKU: 129032801
Availability: InStock

Taian Dongyue Carrying Machinery Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Brand Name:

TAIAN

Model Number:

MS500

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name TAIAN

Model Number MS500

Place of Origin Shandong, China

Type Skid Steer Loader

Moving Type Wheel Loader

Dimension(Long * Breadth * High) 1780x1100x1300mm

Rated Load 500kg

Certification CE&ISO

Warranty one year or 1000 work hours whichever comes first

After-sales Service Provided Engineers available to service machinery overseas

Small engine loader, CE mini loader with backhoe for sale

Advantage

1.Compared with other similar size machine, our MS500 is super powerful with 500kg lifting capacity.

2.We adopted water cooled gasoline engine which has much better cooling efficient, and for such compact machine this is very significant.

3.The unique rotatable oil tank design makes the maintenance much more easier and touchable.

4.The self levering feature also makes it stand out from other mini skids.

5.Different type/brand engines, wheel/track type available, offer many choices to customers

Specifications

Model	MS500 engine mini loader with backhoe
Moving type	Crawler or Wheel
Max. Length (without bucket)	1760 mm
Max. width	1100 mm
Max. height	1295 mm
Speed	5km/h
Rated loading capacity	500kg (including attachment)
Tipping load	1040kg
Max. reach	1800mm
Pushing power	8.2KN
Weight (without attachment)	1050kg
Hydraulic oil flow	30L/min
Track oil flow	46L/min
Oil tank capacity	38L
Oil mode	L-HL46
Gasoline oil capacity	28L/min
Battery capacity	45Ah
Voltage	12v
Wheel size	6.50-10
Inflation pressure	790kpa
Engine	Kohler CH752, 23HP
Engine type	Gasoline, 2 cylinder, air cooled
Rotation speed	3600r/min
Optional Chinese Diesel Engine 1
Engine model	Changchai 3M78, 21.76HP
Engine type	Diesel, 3 cylinders, water cooled
Engine speed	3000r/min
Machine Size(LxWxH/mm) without bucket	1910mmx1150mmx1345mm
Weight (without attachment)	1240KG
Optional Imported Diesel Engine 2
Engine model	Yanmar 3TNV76
Engine Power	25HP
Rotation speed	2800r/min
Engine type	Diesel, 3 cylinders, water cooled
