Pile driver for excavator and wheel loader for sale
pile driver
The most advanced pile drilling equipment
PD Series of spiral pile drilling rig is a new self-innovation spiral pile drilling equipment, widely used in solar power plant constructions, fences, isolation fences, and other pile drilling works for simple houses building, etc.
Excellent Performance
Large torque motor,with strong power and strong adaptability;
Rotary and moving accurate match with the ground conditions, easy adjusting, high piling efficiency;
Matches with pile guiding device, which can ensure the verticality and the accuracy of piles.
Flexible and convenient, good adaptability
*Hydraulic walking system, four-wheel drive, high torque output, strong adaptability;
*Can match with different driving unit with different piles structural dimensions, flexible and efficient for pile installing;
*Quick replacement between rotary and ramming driving unit;
*The drill mast and boom can be quickly disassembled for easy transportation;
Comfortable Operation
High-end practical cabin, elegant appearance, security and comfortable inside;
Equipped with air conditioning, adjustable elastic damping seat;
Full electronic instrument display, the running state of machine is visible inside;
Multifunctional electronic control joystick, with comfortable operation and reducing the work intensity;
Drill mast mounting with electronic inclinometer, easy to adjust and monitor in the cab.
Model |
PD3000 pile driver |
Max. Length |
4370mm |
Max. width (mm) |
1850mm |
Max. height (mm) |
3450mm |
Turning angle |
320 |
Speed |
17km/h |
Weight |
4660kg |
Standard Tyre |
20.5-16 |
Tyre pressure bar |
2.8 bar |
Oil tank capacity |
40 L |
System pressure |
190bar |
Rod diameter |
76-90 mm |
Max. Drilling depth |
3000mm |
Oil model |
L-HL46 |
Engine |
Yunnei 4102 |
Cooling system |
Water cooled |
Rated power |
60kw |
Rotating speed |
2400 r/min |
Fuel tank capacity |
40 L |
Battery |
105AhX2 |
Voltage |
24 V |
1.For the new machine, within determined limits, the manufacture guarantees for a period of 12 months after bought or 1000 working hours(whichever comes first).
2.The warranty includes repairation or replace the parts for free which were proved to be defective in origin by the technical department of the manufacture.
3.The repairation or replacement for the parts should not exceed the warranty period.
4.The warranty is valid on the condition of all the terms listed in the contract was observed.
