4x4 Trucks Electric Forklift FR20

4x4 Trucks Electric Forklift FR20 photo-1
Negotiable MOQ: 11 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
TAIAN
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Shandong, China
Brand Name TAIAN
Model Number FR20
Type Manual Pallet Truck
Power Souce AC Motor
Rated Loading Capacity 2000KG
Max. Lifting Height 4040MM
Min. Lifting Height 2130MM
Fork Length 1070MM
Fork Width 100MM
Overall Dimensions 3350*1160*2130MM
Certification CE and ISO cetificate
After-sales Service Provided Overseas third-party support available

Specifications

battery forklift CPD20C:
a, Mini forklift for narrow and small space
b, Low center of gravity, small turning radius,more sta

4x4 trucks Electric forklift Specifications:

Features

1.2ton electric forklift:
1.Mini forklift for narrow space
2.Low center of gravity,small turning radius
3.Powerful China battery



4x4 trucks Electric forklift FR20



MODEL

FR20

Load capacity

2000 kg

Load center

500 mm

Power type

Battery

Max. lifting speeds(with load)

250 mm/s

Max. driving speeds(with/without load)

12.5/14 km/h

Max towering (with load)

10 kn

Grade ability(with load)

15%

Lifting height

3000 mm

Free lift

60 mm

Tilting angles(forward-backward)

6°/12°

Min. turning radius

2200 mm

Min. Right angle aisle width

2050 mm

Min. under-clearance

110 mm

Dimensions

Overall length(including fork)

3350 mm

Overall width

1160 mm

Overall height(mast lowered)

2130 mm

Overall height(mast extended)

4040 mm

Overall height to overhead guard

2130 mm

Fork width

100 mm

Fork thickness

40 mm

Fork length

1070 mm

Fork overhang

451 mm

Wheel base

1550 mm

Tread

Front tread

970 mm

Rear tread

950 mm

Tire

Front tire

7.00-12

Rear tire

18×7-8

Total weight

3950 kg

Motor

Traction motor

XQ-8

Lifting motor

XQD-10-3S

Battery

Battery type

D-600

Battery voltage/capacity

48V/600Ah

 4x4 trucks Electric forklift FR204x4 trucks Electric forklift FR204x4 trucks Electric forklift FR20
