Home > Products > Chain block > CHAIN BLOCK
CHAIN BLOCK
- 1000 Piece / Pieces per Month
- T/T
Product Details
| Place of Origin | Chongqing, China | Brand Name | DOUBLE SWALLOW | |
| Model Number | HSZ-CA | Usage | Construction Hoist | |
| Power Source | Hand Chain | Sling Type | Chain | |
| Maximum Lifting Weight | 1TON | Maximum Lifting Height | 12M | |
| Certification | GS&CE |
Product Description
Specifications
Series HSZ-CA chain is our newly supplied products on basis of HSZ series.Which possesses good performance in addition the advanHSZ-CA SERIES CHAIN BLOCK
Series HSZ-CA chain is our newly supplied products on basis of HSZ series. Which possesses good performance in addition the advantages as model HSZ series chain block in equilateral triangle appearance, looking more special and beautiful. protects its body seriously with power of anti-collided, the grade of raw material of those cased spare parts has been increased to use longer, which is advanced in design of bottom hook block for chain block of double chains to keep away from chains reversal, the usage of series HSZ-CA is safer.
Model |
| HSZ-0.5CA | HSZ-1CA | HSZ-1.5CA | HSZ-2CA | HSZ-3CA | HSZ-5CA | HSZ-10CA | HSZ-20CA |
Capacity | Ton | 0.5 | 1 | 1.5 | 2 | 3 | 5 | 10 | 20 |
lift | mm | 2.5 | 2.5 | 2.5 | 2.5 | 3 | 3 | 3 | 3 |
Test load | Ton | 0.625 | 1.25 | 1.87 | 2.50 | 3.75 | 6.25 | 12.5 | 25 |
Min.Distance Between Hooks | mm | 280 | 300 | 380 | 392 | 515 | 640 | 730 | 1000 |
Chain pull to lift full load | N | 170 | 340 | 390 | 340 | 390 | 420 | 450 | 450 |
No. of load chain |
| 1 | 1 | 1 | 2 | 2 | 2 | 4 | 8 |
Diameter of load chain | mm | 6 | 6 | 8 | 6 | 8 | 10 | 10 | 10 |
Net weight | kg | 9.5 | 10 | 15 | 14 | 24 | 36 | 68 | 150 |
Gross weight | kg | 10 | 10.3 | 15.7 | 14.5 | 24.8 | 37.3 | 79 | 173 |
Packing measurement ( L X W X H) | cm | 25*18*16 | 25*18*16 | 28*24*18 | 27*20*16 | 32*23*18 | 41*30*21 | 62*50*27 | 80*70*36 |
Extra weight per meter of extra lift | kg | 1.7 | 1.7 | 2.3 | 2.5 | 3.7 | 5.3 | 9.7 | 19.4 |
Remarks: In addition to the standard lift, we accept indent orders up to 12m lift
