I. Usage:
This machine is specially designed for making disposable HIPS/PVC/PET lids for plastic/paper cups, mini soup spoons, trays for medicine and etc.
II. Main Features:
1. This machine adopts sheet roll feeding, heating, molding, hole or cross punching, trimming, finished products transmission automatically, which saves labor and avoids product pollution during the production.
2. This machine is controlled by PLC with interface, which is easy operation and maintenance.
3. The journey of this machine is adjustable, and easy to change the moulds for different sizes of products.
In a word, this is a perfect machine with small workshop requires, less electricity consumption, less labor invests, less waste sheet appears, but high output, favorable price, easy operation and maintenance.
III. Main Technical Parameter:
Model |
SPBG-400A |
Suitable Material |
PS/HIPS/PVC/PET |
Journey Range |
30-160mm |
Max Forming Area |
400×160mm |
Max Forming Depth |
32mm |
The Power of Heater |
1.5KW*2pcs |
Total Power |
4.6KW |
Required Sheet Width |
340mm |
Required Sheet Thickness |
0.15-0.5mm |
Air Pressure |
0.4-0.7MPa |
Air Consumption |
0.6-0.8m3/min |
Water Consumption (recycle) |
60 liters/hr |
Punching Frequency |
8-32 times/min |
Total Power of Electric Source |
380V 50HZ 4.5KW |
Weight |
800Kg |
Dimensions |
2700×830×1450mm |
IV. Some Thermoforming Moulds:
V. Some Thermoforming Samples:
More details of the machine, pls contact with Ms. Maggie Lin
Skype: maggielam718
Trade Manager ID: sinoplast2013
Mobile: 0086-13958816227
