Specifications
1,double lane bagging filling machine2,high efficiency and take less place
3,good quality
4,good price
This machine consisits of a cup metering device and a double -line VFS 5000DS vertical filling-packaging machine,especially suitable for the metering packaging of fine-partical products,It intergrates the functions of metering,bag-making,sealing,printing, and counting.Its operating interface adopts the advance touch screen and has the automatic bias-correction function.
| measuring capacity | 300-1000g |
| packing speed | 100-120 bags/min |
| bag type | pillow bag |
| bag size | L:50-280mm W:80-200 |
| measuring accuracy | 1% |
| compressed air requirement | 0.6Mpa 0.36m³/min |
| film width | 120-420mm |
| power consumtion | 380V 50HZ 5.5KW |
Advantage:
- Machine fully controlled by Siemens or Omron PLC & Touch-Screen.
- Minute capacity can automaticlly display on Touch screen.
- Film transport system and horizontal Jaw motion both drived by servo motor.
- Optoelectronics detect film position on collar to correct film excursion.
- Electrical photo sensor inducting color code to contol bag length.
- Independent temperature adjustment& code printing system.
- Various types of heating sealable laminated films namely PE/BOPP, CPP/BOPP, CPP/PET, PE/NYLON, aluminum foil based can be run on the machine.
- Can euqiped with hole punching system to puch hole on the bag for handling
