Help CenterVFS7300B Automatic Weighing Packaging Machine
Related Products
-
Tomato Ketchup Liquid Packing Machine for OilUS$ 6,000 - 10,000MOQ: 1 Set -
VFS5000D Automatic Cup Filling and Packaging MachineUS$ 7,000 - 10,000MOQ: 1 Set
-
DXD110 Automatice Tea Leaf Packaging MachineNegotiableMOQ: 1 Set
-
VFS7300YA5 Powder Packaging MachineUS$ 28,000 - 32,000MOQ: 1 Set
-
VFS5000B POWDER PACKAGING MACHINEUS$ 30,000 - 35,000MOQ: 1 Set
Specifications
1, Can be equipped with weighing & filling system2, Pillow type or gusseted bag
3, Adopt film automatic correction device
The unit of machine is 2014 new type packing machine that suit for granular material packaging. This machine can independently compete the weighing, bag making, filling (air filling or exhausting), sealing, hole punching, code printing, and bag counting etc. It includes liner weigher packaging machine and elevator. It adopt film automatic correction device. The horizental sealing jaw can be driven by both air cylinder and servo motor.
Bag type: |
Pillow Type Bag; Gusseted Bag |
Capacity: |
200-5000g |
Speed: |
20-50BPM |
Weighing accuracy: |
±0.2% depending on products characteristics |
Bag size: |
50 to 460mm (L); 80 to 350mm (W) |
Reel film width: |
≤730mm (28.7in) |
Reel outer dia.: |
500mm (19.7in) |
Reel inner dia.: |
75mm (2.9in) |
Power consumption: |
7KW |
Compressed air requirement: |
0.6MPa0.36m3/min |
Advantage:
- Machine fully controlled by Siemens or Omron PLC & Touch-Screen.
- Minute capacity can automaticlly display on Touch screen.
- Film transport system and horizontal Jaw motion both drived by servo motor.
- Optoelectronics detect film position on collar to correct film excursion.
- Electrical photo sensor inducting color code to contol bag length.
- Independent temperature adjustment& code printing system.
- Various types of heating sealable laminated films namely PE/BOPP, CPP/BOPP, CPP/PET, PE/NYLON, aluminum foil based can be run on the machine.
- Can euqiped with hole punching system to puch hole on the bag for handling
