Liquid and Paste Sachets Packing Machine for Shampoo, Potato Paste, Ketchup

Name: Liquid and Paste Sachets Packing Machine for Shampoo, Potato Paste, Ketchup
Brand: Zengran
SKU: 128953231
Availability: InStock

US$ 3,000 - 10,000 MOQ: 1 Set

Key Specifications

Condition:

New

Function:

Filling, Sealing, Other

Application:

Chemical, Commodity, Food, Other, Medical, Other, Chemical, Commodity, Food, Machinery & Hardware, Medical, Other

Anhui Zengran Packaging Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Function Filling, Sealing, Other

Application Chemical, Commodity, Food, Other, Medical, Other, Chemical, Commodity, Food, Machinery & Hardware, Medical, Other

Packaging Type Bags, Film, Foil, Pouch, Stand-up Pouch, Other

Packaging Material Wood, Other

Automatic Grade Automatic

Driven Type Pneumatic

Voltage 220V/50HZ

Power 2.5kw

Place of Origin Anhui, China

Brand Name Zengran

Model Number ZR-60YB

Dimension(L*W*H) L800xW800xH1700mm

Certification CE/ISO9001

After-sales Service Provided Engineers available to service machinery overseas

Liquid and paste sachets packing machine for shampoo, potato paste, ketchup

Specifications

No.	Equipment name	Technical parameters
1	Model	ZR-60YB(normal/frequency and speed control)
2	Packing speed	30-60bags/min
3	Dosing range	1-100ml(according to the characteristics of material,the measuring cup will be changed)
4	Bag size	(L)40-200,(W)40-110mm
5	Sealing Type	Three side sealing
6	Total power	1350w
7	Machine weight	260KG
8	Voltage	220V,380V/50Hz
9	Power	2.5kw
10	Packing Material	paper/PE,Polyester/aluminum foil/PE,nylon/polyethylene,tea filter paper,etc.
11	Overall Size	L800×W800×H1700mm
12	Optional Equipment	Thermal Printer Conversion from trilateral seal to quadrilateral seal Venting Device Easy-to-Tear-Knife-Device Flat cutter,Tooth cutter,continious point cutter

Configuration list

PATRS LIST	BRAND
PLC	FATEK
Touch screen	WEINVIEW
frequency converter	Bushnell
temperature-controlled meter	Chinese brand
SSR	Schneider
AC contactor	CHINT
Air switch(with RCD)	CHINT
Ribbon coding unit	Chinese brand
