Desktop Motorized LCD Monitor Lift / Conference System Motorized Monitor Lifter

Specifications

Monitor Lift
1,Suit for below 17 inch screen
2,aluminum alloy finishing
3,5mm panel thickness
4,LCD lift up and down

Desktop Motorized LCD Monitor Lift / Conference System Motorized Monitor Lifter



LCD lift introduction:

Desktop LCD Motorized Lift is advance hiding equipment designed for audio video system in office furniture. The LCD screen of LCD monitor lift would be rising down into the desk and hidden under the office table when unused; Screen inside the LCD  lift would be rising up from table automatically by touch switch or remote control and present the workable screen on the desktop if used.



LCD Monitor Lift Feature:

1, The panel of LCD lift is aluminum alloy, with aluminum wire drawing process on surface.

2, The Monitor Lift adopts synchronous orbit lifting principle.

3, Desktop Vertical Monitor Lift works smoothly and quietly. Low noise which less than 30db.

4, LCD Screen Lift provides protecting function of LCD monitors by cutting the electricity off automatically.

5, LCD monitor Lift would be adjustable elevation angle of LCD monitor for protecting your eyes from the direct light.

5, Tabletop Monitor Lift is controlled by two big AC motors. One controls opening and closing the panel of LCD monitor Lift; one controls lifting the monitor up and down and adjust the angles of the monitor.

6, Control system: Touch Switch on LCD motorizedLift panel, RF remote control, RS232 AND rs 485 central control.



LCD Monitor Lift Characteristic

1, high quality aluminum alloy finishing with motors

2, A=A strong carton with foam cushion and waterproof film

3, white/black/gold color is available for color selection

4, Power plug and voltage could be changed accordingly.

5, OEM with logo on product and packing is available

6, Customized made is available



LCD Monitor lift Application:

LCD Monitor Lift is widely used on conference system, like video conference system, tv conference system, financial analyzing system, advanced office system, lecture and training room with conference table& computer desk together.



LCD Monitor Lift Parameter:

Item Model	BLL-17
Style	LCD lift without monitor
Products consitute	LCD monitor lift+ Remote control
Panel size	485*145*5mm
Box size	463*130*578mm
Panel thickness	5mm
Lift mount size	405*75mm
Packing size	60*27*78mm
Voltage	110V,220V,240V
Power	20~25W
Tilting angle	0~15°
Single trip time	30s
Working temp	5~40
Environmental temp	­20~60
Related humidity	20~80%
Color	Silvery/Black matt/ Golden
Remote distance	10m
Material	Aluminum alloy draw bench panel
Control Way	Touch key-press/ Remote control/RS485 central control
Running Way	Tubu motor with rack driving
Protection way	Cable Manager/Protection finger from nipping
Power Protection way	Monitor turn off automatically

LCD Screen Lift Drawing:

LCD Monitor Lift Professional Service:

1, Any of inquiries will be response within 48 hours

2, Sizable accessories of products for replacement

3, Sample of LCD monitor lift is available.



Warranty:

Study the user’s manual carefully before installation.

All of our products provide 12 months warranty! The warranty period starts from the goods receipt by initial consignee.



Payment:

T/T, L/C, Western Union, Money Gram, Crash is acceptable



LCD Monitor Lift Pictures:
