Yulong Brand Biomass small wood pellet stove
We produce biomass pellet making line machines, such as wood logs debarking machine, wood logs splitter,
wood sawdust making machine ,wood chipper, hammer mill, grass/straw cutter , straw bale crusher ,pellet
machine and briquette machine, dryer and cooler, screener, mixer , biomass pellet boiler ,pellet packing
machine and all conveyors, pellet boilers and pellet burner e. c. t. Our factory has more than 18 years history, CE and ISO9001 high quality certificate,for wood pellet burner details, as below :
1.Biomass wood pellet stove is wildly used in various industries such as boiler, casting machine,industrial
stove, smelting furnace,kitchen equipment,drying equipiment ,food drying equipment,ironing equipment ,
lacquer equipment,Road building machinery equipment,Industrial annealing furnace,asphalt
heating equipment .
2.Biomass wood pellet stove adopts biomass pellet as fuel,YULONG brand burner is more
wildly used and has lower requirement for fuel quality.
Working performance of wood pellet stove
1.using biomass pellet as fuel
2. burning efficiency is larger than 95%,Boiling type half gasification combustion and tangent of swirling
air distribution design, makes fuel fully burned .
3. Fully burned and burning stable. In micropressure situation not happen tempering and flamelifting
phenomenon
4.heating load can be wildly adjusted, can quickly adjust between 30%-130% of rated load,Initiate Block
reaction is sensitive
5.no pollution and high efficient environmental protection, burn reproducible biomass fuel,Realize the
sustainable use of energy. It adopts low temperature section burning technolgoy, the nitrogen oxides,
sulfur dioxide ,dust etc in smoke are low, which is the best substitute for coal stove etc
6. Easy operating,convenient Maintenance, automatical feeding, automatical discharging,automatical igniting,
automatical control temperature ,automatical 24 working hours without unattended substation
7.low invest, low working cost ,wide belt burning with frequency conversion, more fit for user requirement and
can change burning type ,controling as per their requirement .
YULONG BIOMASS PELLET BURNING MACHINE HOT SALE IN 2015 SPAIN EXHIBITION.
Technical Parameter of wood pellet stove:
Model |
Calorific value (Kcal/h) |
Match Boiler Capacity |
Power (Mw) |
Fuel consumption (KG/h) |
Fire Port Diameter (mm) |
Dimension (mm) |
Weight (Ton) |
Fan power (kw) |
Ash remove grate |
|
L*W*H | ||||||||||
YLR-30Q |
300,000 |
0.5T |
0.55 |
71.4 |
Φ150 |
2200*1000*1300 |
1.8 |
1.5 |
Fix grate |
—— |
YLR-60Q |
600,000 |
1T |
0.7 |
142.9 |
Φ200 |
3000*1700*1800 |
3.5 |
4 |
Fix grate |
Traveling grate |
YLR-120Q |
1,200,000 |
2T |
1.4 |
285.7 |
Φ300 |
3850*2000*2250 |
4 |
7.5 |
Fix grate |
Traveling grate |
YLR-180Q |
1,800,000 |
3T |
2.1 |
428.6 |
Φ400 |
4700*2250*2480 |
5 |
12 |
—— |
Traveling grate |
YLR-240Q |
2,400,000 |
4T |
2.8 |
571.4 |
Φ500 |
5200*2480*2650 |
6 |
16 |
—— |
Traveling grate |
YLR-360Q |
3,600,000 |
5-6T |
4.2 |
857.1 |
Φ700 |
5800*2900*3100 |
7 |
30 |
—— |
Traveling grate |
YLR-480Q |
4,800,000 |
7-8T |
5.6 |
1142.9 |
Φ900 |
6500*3400*3800 |
9 |
40 |
—— |
Traveling grate |
