Help CenterHot Sale Grass/Stalk Hammer Mill Machine
Related Products
-
PVC Foaming Board Multifunctional Hammer MillUS$ 300 - 6,000MOQ: 1 Set -
YULONG Multifunctional Hammer Mill Made in ChinaUS$ 300 - 6,000MOQ: 1 Set
-
Maize Grinding Mill Price CE CertificationUS$ 300 - 6,000MOQ: 1 Set
-
SG Wood Chips Crusher Price/Hammer Mill CE ApprovedUS$ 300 - 6,000MOQ: 1 Set
-
Small Corn Mill Grinder for SaleUS$ 300 - 6,000MOQ: 1 Set
Introduction
1.Multifunctional hammer mill is the most ideal grinding equipment for all kinds of wood chips, wood shavings, grass, straw, stalk, rice husk and palm fiber etc. When crush plastic,PVC and rubber etc., it adpopts water cooling structure, avoiding the damage to spare parts due to long time working friction, except biomass. It also can crush animal feed materials such as soybean, maize, cereal and fertlizer materials from animal manure, chemical etc. which is mainly used in wood factory,feed factory, organic fertilizer factory, and so on.
2.We will install fit hole screener sieve at the hammer mill bottom according to materials humidity.If raw materials were high humidity , then we will install 10-30mm hole screener even no screener at the bottom. If dry, then will install 2-4mm hole screener, which means will outlet smaller than 2mm fine powder.
3.The hammer mil key spare parts such as hammers and screener are made by our CNC systems, through high technical heat treatment, standing out from other suppliers is that we could ensure the parts high precision and good quality.
4.The hammer mill works connect with air fan and cyclone,air lock ,dust filter ,after crushed ,the powder will outlet from cyclone bottom, which is very environmental protection and easy to collect dust.
Technical Parameter:
Model |
Capacity(t/h) |
Power(kw) |
|||||
Crude fiber |
Animal feed/fertilizer |
PVC fine grinding |
Animal feed/fertilizer |
Crude fiber |
PVC |
||
SG40 |
Φ5 0.1-0.3 |
0.3-0.8 |
|
7.5 |
|||
SG50 |
Φ6 0.2-0.4 |
Φ2-φ6 0.5-1 |
|
15 |
|||
|
SG65*27 Belt drive |
Φ6 0.5-0.8 |
Φ2-φ6 0.5-2 |
|
22 |
|||
|
SG65*27 Gear drive |
Φ6 0.6-1 |
Φ2-φ6 1-3 |
|
||||
65*55 |
Φ6 1-2 |
Φ2-φ6 2-3 |
Φ2-3.5 0.2-0.5 |
37 |
37-55 |
37 |
|
65*75 |
Φ6 2-3 |
Φ2-φ6 3-5 |
Φ2-3.5 0.3-0.8 |
55 |
55-75 |
55 |
|
65*100 |
Φ6 3-4 |
Φ2-φ6 4-6 |
Φ2-3.5 0.5-1
|
90 |
90-110 |
90 |
|
Features:
1.Multiple functions, SG hammer mill can handle most raw materials;
2.Rotor structure. It ensures no dead corner inside and makes the finished products evenly;
3.Vibration tested. SG series is our mature products, all the SG series hammer mill had vibration
test before they are ready to sell. As a result of that, SG hammer mills have little shaking which
makes the machine works smoothly and safety.
4.The hammer mill must works with cyclone, the cyclone can filter out the dust from finished products.
Video website:
Application:
Hammer mill in our showroom:
Hammer mill with water cooling system:
Diesel power:
Delivery:
Please do not hesitate to contact me if any questions.
