GHG Rotary Drum Dryer for Biomass | Fertilizer | Feed Raw Materials

Name: GHG Rotary Drum Dryer for Biomass | Fertilizer | Feed Raw Materials
Brand: YU LONG
SKU: 128914459
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Drum Drying Equipment

Place of Origin:

Shandong, China

Jinan Xucheng Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Drum Drying Equipment

Place of Origin Shandong, China

Brand Name YU LONG

Model Number GHG

Voltage 380V(or other)

Certification CE ISO SGS

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

Specifications

GHG rotary drum dryer for biomass | fertilizer | feed materials
1.CE ISO SGS
2.high efficiency
3.patent product

GHG rotary drum dryer for biomass | fertilizer | feed raw materials

Rotary drum dryer is mainly to dry biomass or Fertilizer or animal feed powder materials , it has changeable speed rotary

drum , which can dry high humidity materials, such as to dry biomass from sawdust, straw, stalk, animal feed materials from maize,

soybean,cereal fertilizer materials from poultry manure , home or factory waste ect .

Rotary drum dryer can be controlled according to raw materials humidity. If humidity is large, then can control feeding

speed lower and drum RPM lower to make longer drying time.

Rotary drum dryer has temperature adjusting equipment between stove and dryer, which can adjust hot air temperature when

feeding to dryer drum according to raw materials humidity and outlet stove hot temperature

Rotary drum dryer has two ways to discharge materials, one is to outlet from rotary drum bottom, it is mainly fit for large

weight ratio materials , the other is to outlet materials from cyclone bottom , which mainly fits for light ratio materials .so

please tell us what kind of raw materials and dimension, raw humidity, then we will help you choose best dryer model.

Model	Power (kw)	Steam Evaporation capacity (ton)
QHG0.861	4+3	0.1-0.2
QHG0.8121	4+5.5	0.2-0.3
QHG0161	4+7.5	0.2-0.3
QHG01121	5.5+7.5	0.4-0.5
QHG01.2121	5.5+7.5	0.4-0.6
QHG1.4121	5.5+11+7.5+3	0.6-0.8
QHG1.5121	5.5+15+7.5+4	0.8
QHG1.6121	5.5+18.5+7.5+4	0.8-1
QHG1.6241	7.5+22+15+5.5	1.1-1.2
QHG1.8121	7.5+18.5+11+4	0.8
QHG1.8123	11+30+5.5	1
QHG1.8241	11+30+4	1
QHG2121	7.5+22+11	1.2
QHG2123	11+45+5.5	1.5
QHG2241	7.5+37	1.2
QHG2.2121	7.5+22+4	1.2
QHG2.2123	11+45	1.5
QHG2.2241	7.5+37	1.8
QHG2.5121	15+22+4	1.5
QHG2.5123	18.5+45	1.8
QHG2.5241	15+37	1.8
QHG2.8121	18.5+30+4	1.8
QHG2.8123	22+55	1.8
QHG2.8241	22+45	2.4
QHG3121	22+45+4	2.5
QHG3123	30+55	2.5
QHG3241	22+45	3
QHG3.5241	30+45+5.5	3.6
QHG3.5123	75+45	3.8
QHG3.5241	22+45	3
