Help Center2016 Good Corlorful Aluminum Coil Coating Line
Related Products
-
Aluminum Coil Cleaning Coating Sheet Metal LineUS$ 160,000 - 280,000MOQ: 1 Set -
Hot Sell Aluminum Coil Coating Line MachineUS$ 160,000 - 280,000MOQ: 1 Set
-
Zhejiang Aluminum Coil Color Coating Line Cleaning MachineUS$ 160,000 - 280,000MOQ: 1 Set
-
China Factory Coating Line Production Cleaning MachineryUS$ 160,000 - 280,000MOQ: 1 Set
-
Professional Cleaning Machinery Line ProductUS$ 160,000 - 280,000MOQ: 1 Set
- The main specification of the equipment
3-1 Raw material: Aluminium or Aluminium Alloy coil
Width: 910~1,600mm
Thickness: 0.10~0.50mm
Coil inner diameter: φ150/405mm
Coil exterior diameter:φ1,200mm(max)
Coil weight: 3,000kg(max)
3-2 Assistant material:
Specification |
Fluorin Carbon |
Polyester Dope |
Acrylic acid dope |
Coating viscidity (4 cups) |
60~120 |
60~110 |
55~110 |
Thickness of the dry film μm |
15~25 |
15~25 |
15~20 |
Dry temperature (°C) |
249~254 |
210~224 |
183~210 |
Line speed M/min |
8~15 |
10~20 |
10~25 |
3-3 Heating time: 220°C/60mins
3-4 Heating method:
Stainless steel resistance fim heating unit
S.C.R. silicon controlled adjustable electricity output
Temperature controller: PID automatic calculation procedure temperature-controller
3-5 Electricity:
Main power: 3φ-380V-50HZ
Electric power: 484.2KW(heating)+ 70HP(motor)
Practical power: 280kw
3-6 Pressure of condensed air
Pressure: 5~6kgf/cm2
Air quantity: 0.2~0.8M3/min
3-7 Water quantity: Industry water
Water pressure:: 0.5~2.0kg/cm2
Water quantity: 0.1~0.5M3/hour
3-8 Equipment speed: 0~30M/min
3-9 Equipment size: 52,000L×4,000W×5,200H mm
3-10 Equipment weight: 96,000kg(approximately)
Advantages :
1, The features of ACP product include: light weight, easy to formed, easy to construct, rich in colors, oxidation-resistant and radiation-resistant, etc.
2,Formation and clean production company uses aluminum coil line is equipped with a waste recycling system to ensure that meet emission standards and an increase of 40% of calories consumed
| Delivery time | Delivery within 30 days |
| Standard packaging | Wood box and plastic film package |
Taizhou Yushen Machinery Co., Ltd is an equipment manufacturer that designs and produces professional aluminum coil cleaning production line, aluminum coil coating production line, aluminum composite panel production line and auxiliary equipments. Established in 2009, the company is located in Jiaojiang District, Taizhou, Zhejiang Province.
The motors or electrical components used in the company come from international brands such as Siemens, Schneider, Mitsubishi and Delta, assuring the reliability and stability of the line. The company also employs AC frequency servo control and automatic tension control to make it easy to adjust the speed and convenient to operate and maintain.
Our company has provided aluminum composite panel complete production line of advanced technology and high quality to clients home and abroad, such as Zhejiang, Hebei, Jiangxi, India, Saudi Arabia, Iran, Burma and Uzbekistan, etc.
| Q1:Our Services |
|
A:(1)Our company is established in 2009 (2)Our company has provided aluminum composite panel complete production line of advanced technology and high quality to clients home and abroad, such as Zhejiang, Hebei, Jiangxi, India, Saudi Arabia, Iran, Burma and Uzbekistan, etc. |
| Q2:What is ACP? |
| A:ACP is a joint product which is produced by hot-pressing polyethylene plastic and heated and pressed aluminum sheet. The features of this product include: light weight, easy to formed, easy to construct, rich in colors, oxidation-resistant and radiation-resistant, etc. It is widely used in fields such as decoration, advertisement, furniture, automotive and so on. |
