Help CenterMicro Coating Thickness Meter CM-1210-200N 0~200 um / 0~8mil
Related Products
-
Micro Coating Thickness Meter CM-1210-200F 0~200um/0~8 MilUS$ 300 - 450MOQ: 1 Piece -
Plating Thickness Tester for Vehicle CM-8828 0~1250 Um/ 0~50 MilUS$ 165 - 250MOQ: 1 Piece
-
Wet Film Comb CM-8000 Coating Thickess GaugeUS$ 8 - 30MOQ: 1 Piece
-
Digital LCD Coating Thickness Gauge CM-1210B 0~2000 um / 0~80 MilUS$ 170 - 220MOQ: 1 Piece
-
New Coating Thickness Gauge CM-1210A 0~2000 Um/0~80 MilUS$ 160 - 220MOQ: 1 Piece
Applications:
The N probes measure the thickness of non-conductive coatings on non-magnetic metals. It is used on anodizing, varnish, paint, enamel, plastic coatings, powder, etc. applied to aluminum, brass, non-magnetic stainless steel, etc.
* Specially for the thickness measurement of coating on small workpiece.
* Measuring methods: eddy current (N).
* Two measurement mode: Single and Continuous(Notice:Continuous mode is convenient to measure the
coating thickness of curved objects and tiny objects.)
* Metric/imperial system selectable.
* Manual or automatic shut down.
* Auto memory of calibration value,and auto recognize the substrate.
* Operation process have buzzing reminder,while no buzzing in continuous mode.
* Use “USB data output” and “RS-232 data output” to connect with PC.
* Provide “Bluetooth data output” choice.
* Separate Type, measurements can be more flexibility.
Operating Principle |
Eddy Current (NF) |
Measuring Range |
0~200 um / 0~8 mil |
Resolution |
0.1 um |
Min. Radius Workpiece |
convex 2 mm / concave 4 mm |
Min. Measuring Area |
2 mm |
Min. Sample Thickness |
0.1 mm |
Accuracy |
± 1~3%n or ± 2.5 um |
Auto Power Off |
|
Metric / Imperial |
Convertible |
Battery Indicator |
Low Battery Indicator |
Operating Conditions |
Temp. 0~40 °C, Humidity: 10~90 %RH |
Power Supply |
4 x 1.5 V AAA (UM-4) Battery |
Dimensions |
140 x 72 x 34 mm ( 5.5 x 2.8 x 1.3 inch ) |
Weight |
215 g (Not Including Batteries) |
Standard Accessories:
1. Main Unit
2. Probe (NF Type)
3. Calibration Base Set (NF Type) CTG-BS
4. Calibration Foils CTG-CF (1 set, 4 pieces)
5. Carrying Case
6. Operation Manual
Optional accessories:
1. USB, RS-232C data cable with software
2. Bluetooth data out put with software
