Sonar Echo-sounders HD370 Underwater Echo-sounders
Digital Echo Sounder |
HD370 Single Frequency |
HD380 Dual Frequency |
Frequency |
200 KHZ |
High: 100-750KHZ(Adjustable) Low: 10-50KHZ(Adjustable) |
Transmission Power |
500W (200KHZ transducer) |
500W (200KHZ High frequency band) 1000W (20KHZ Low frequency band) |
Bathymetric Range |
0.3m-600m |
0.3m-600m (High frequency) 0.3m-2000m (Low frequency) |
Depth Resolution |
0.1ft/0.01m |
|
Accuracy |
±0.01m+0.1% of h( depth value) |
|
Ping Rate |
Up to 30Hz |
|
Draft Range |
0.0m~15m |
|
CPU |
1.6GHZ |
|
Memory & Storage |
1G DDR2 & 4G storage |
|
LCD Display |
12 inches, 1024X768 resolution, 1000cd/ m2 |
|
I/O Interface |
2×RS-232 ports, 3×USB ports, 1×DC power port, 2×TX ports (for transducer) |
|
Power Supply |
DC 9~36V / AC 220V |
|
Operation Temperature |
-30°C~60°C, non-condensing |
|
Dimension |
44mmL X 341mmW X 164mmH |
|
Weight |
9 kg |
|
With advanced frequency conversion technology, HD-370 and HD-380 reduce noise caused by transducer and enhanced echo intensity. In addition, both the HD-370 and the HD-380 support different frequency transducers to meet the demands of different hydrographic projects.
l The optimal TVG curve of HD-370 and HD-380 is designed according to the transmission properties of sonar in water which can greatly optimize sounding performance and solve the issue of shoal water sounding.
l Portable design, high-definition LCD screens and mass storage make field operations much more convenient.
l Preinstalled Hi-Sounder software reduces your software cost.
l With the low frequency sounding function, HD-380 can easily get mud thickness data.
