JGS-1B 3000m Well Logging Survey System
Main Applications and Features
- Coal Field Digital Integrated Logging
- Hydrological Engineering Digital Integrated Logging
- Solid Metal Ore Digital Integrated Logging
- Other Minerals Digital Integrated Logging
- External Laptop (Desktop PC)
- For upward logging, also for downward logging
- Receive digital signal, analog signal
- 8 taps of power supply current, Optional
- Automatic sampling as per depth interval, sampling interval arbitrarily
- Indoor simulation logging, repeatability observation of instruments and probes
- Membrane panel, attractive and durable
Technical Specifications
- 12bit A/D Conversion, Program-Controlled Magnification K=0.5~128
- Counting Channel: f≤500KHz
- Digital Signal Transmission Frequency: 9600bit/s
- Power Supply Cycle: 400ms
- Current: 2mA~500 mA Optional
- Signal Input Range: ≤±10V
- Continuous Working Time: ≤24 hr
- Power Consumption: <200W
- Volume: 420×260×210mm,
- Weight: <7Kg
- Working Temperature Range: -10℃~ +50℃
- Working Power Supply: AC220V±10% 50Hz ±5%
-
Logging Speed: 0~30 m/min Adjustable (as per sampling interval)
Logging Working Software System:
12bit A/D Conversion, Program-Controlled Magnification
Operation Environment: Windows98/2000/XP
Sampling Interval: Arbitrary (1~1000cm)
Setting (1cm, 2cm, ...1000cm)
Maximum depth of one-time acquisition: 3000m (0.1m sampling interval)
Depth automatic alignment of multi-parameters
Superposition of multi-parameters up to 10
Curve movement, anomaly removal, smoothing, inverted order, segmentation, calculation, etc.
Interpretation of profile input, automatic generation of rock stratum name, thickness and baseplate depth
Curve amplification and compression
5 types of curve depth ratio: 1:50, 1:100, 1:200, 1:500, 1:1000
Continuous drawing production in color or black-and-white effects
Output graph maximum width:415mm, length:2310mm
Test situation:
Any questions about Well Logging Survey System,please contact Elsa.
Phone/whatsapp/wechat:0086-15922980256
Skype:goldinstrument
