Product Details
| Place of Origin: | Chongqing, China | Brand Name: | Gold | Model Number: | JGS-1B |
Product Description
Coal Field Digital Integrated Logging
Hydrological Engineering Digital Integrated Logging
Solid Metal Ore Digital Integrated Logging
Other Minerals Digital Integrated Logging
External Laptop (Desktop PC)
For upward logging, also for downward logging
12bit A/D Conversion, Program-Controlled Magnification K=0.5~128
Counting Channel: f≤500KHz
Digital Signal Transmission Frequency: 9600bit/s
Power Supply Cycle: 400ms
Current: 2mA~500 mA Optional
Signal Input Range: ≤±10V
Continuous Working Time: ≤24 hr
Power Consumption: ＜200W
Volume: 420×260×210mm,
Weight: ＜7Kg
Working Temperature Range: -10℃~ +50℃
Working Power Supply: AC220V±10% 50Hz ±5%
Logging Speed: 0~30 m/min Adjustable (as per sampling interval)
