S22 Widely Used Visible Spectrophotometer

S22 Widely Used  Visible Spectrophotometer

Application :

Model S22 Visible Spectrophotometer is a compact and easy to operate instrument. It can be applied in measurement
of transmittance, absorbance and direct concentration readout of transparent material. They have been versatility
employed in the fields of hygiene and medicine, clinical examination, biochemistry, petrol chemical engineering,
environmental monitoring and inspections, and quality controls for qualitative and quantitative analysis of concerning
samples.

Features

1.  Aspherical light source optics, C-T configuration diffraction grating monochromator.

2.  Simple & clear keyboard operation is convenient to realize auto 0% T &100% T adjustment T/A transformation,

factor setting and direct concentration readout function.

3.  With RS232 parallel l interface.

4.  RS232 serial interface, micro printer can be chosen for printing data directly; data processing package

compatible, Transmittance and Absorbance Standard Curve Mode, Quantitative Analysis Mode are provided.

5. Spacious sample compartment, 4 position cell rack, adaptable for 1-5 cm optical path rectangular cells.

Specifications

1. avelength Range: 340-1000nm

2. Wavelength Accuracy: ±2 nm

3.  avelength Reproducibility: 1 nm

4. Band width: 6 nm

5. hotometric Accuracy: ±0.5%t (SRM930D)

6. hotometric Reproducibility: 0.3%t

7. Stray Light: ≤0.5%t

8. oise: ±0.5%t

9. cale Display:

i. TRANS: 0-199.9%

ii. ABS: -0.3-2.999

iii. FACT: 1-9999

iv. CONC: 0-9999

9. ight Source Lamp:

Halogen-Tungsten Lamp 20W/12V

10. Power: 220V/110V±10% 50/60 Hz

11. nterface: RS232 serial & parallel l interface
