Diamond Tools For Mechanical Engineering with Nx Diamond Core Drill Bits
XY-8B Diamond Tools For Mechanical Engineering Features:
- Machine adopts pneumatic shift Fastgear 8JS118 auto transmission and clutch, compact structure, smooth operation, stable performance, good wildcard.
- Using auto-control flexible-shaft shift agency, we achieve the long-distance transmission shift. The pneumatic shift is light and agile, and has the advantage of hommization.
- Reasonable speed range and many speed radixes (8 forward speed, 1 reverse speed), with low-speed it has big torque (Max. up to 8000N.m).
- Using concentrated forced lubrication system, as long as the rig runs, the separate lubrication oil pump starts working and sends lubrication oil to each node that requires lubrication. When the oil lubricates drive mechanism, it will also take away the heat inside, (lubrication system with separate condenser), to prevent the components from heat caused by high-speed high-load state.
| Drilling depth (m) | 1000-3200 |
| Drilling rod (mm) | 50.5 60 71 73 89 114 |
| Drilling angel | 90-80 |
| Spindle speed (r/min) |
(forwards) 79 137 213 223 266 384 604 1024 (reverse) 51 144 |
| Pulling capacity (KN) | 300 |
| Feeding capacity (KN) | 142 |
| Feeding stroke (mm) | 1000 |
| Max single-line hoisting force (KN) | 130 |
| Lifting speed (m/s) | 0.57-7.58 |
| Steel wire (mm) | 21.5 |
| Rope capacity (m) | 160 |
| Skidding cylinder stroke (mm) | 690 |
| Motor engine | 90kW Y2280M-4 |
| Diesel engine |
132kW 6BTA5.9-C180 |
1. Inudustrial professional export packing, full inspection on all packing details.
2. Standard wooden case for Nx Diamond Core Drill Bits exporting and shock absorbing for better outerior protection.
3. Considerate interior plastic sheeting protection to prevent from wet and moisture.
Chongqing Gold Mechanical & Electrical Equipment Co., Ltd. is the professional manufacturer in Geophysical instruments. Over 15 years experience engineers, and well-trained technicians, workers work together to back up our production line. We supply professional Drilling rigs with high quality and competitive price, such as: Core/Rock Drilling, Sample Drilling, Water Well Drilling, Down the hole Drilling, Truck, Crawler, Trailer, Tricycle mounted Drilling. We won high reputation from our customers mainly from Southeast Asia, Africa, Middle East, also including customers from Canada and some western countries like Germany, France. We do not just do trade business like doing Mechanical Engineering, but doing the business for providing better Customer Experience! Sincerely welcome your inquiries!
