180m Ground Hole Digging Machine and Geothermal Perforation

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Rotary Drilling Rig
Power Type	Diesel	Place of Origin	Chongqing, China
Brand Name	Gold	Model Number	HZ-180YG
Usage	Water Well	Voltage	380V
Power(W)	11kw	Dimension(LWH)	2.71.11.3m
Weight	3500kg	Certification	ISO9001
Warranty	1 year	After-sales Service Provided	Engineers available to service machinery overseas

180m Ground Hole Digging Machine and Geothermal Perforation

Applications:

HZ-180YG drilling rig is mainly used for geological general investigation and exploration, road and tall

building foundation exploration, kinds of hole in concrete structure, river levees,civil wells and earth

temperature central air-conditioner,etc.

Features:

1. Highest speed can reach 1045r/min, improving drill efficiency

2. 53 x 59 drilling rod adopted, with high rigidity and strong delivery torque.

3. The machine is equipped with national patent technology taper clutch, with strong transmission

torque, easy operation and free of maintenance.

4. For the winch, we use large module planetary gear and add supporting frame, greatly increasing

hoisting and braking ability of the winch.

5. Vertical spindle is fixed by four sets of bearings to ensure that the rotary machine is rigid enough

for gravel layer and other complex geoloical conditions.

Technical specification:

Unity machine parameter
Drilling depth	30--180m
Drill rod caliber	50 42mm
End hole caliber	75 46mm
Max. open hloe caliber	220mm
Drilling angle	90°~75°
Drill weight (No include power)	610kg
Unity machine dimensions	2.1×0.9×1.3m
Spindle
spindle speed	130, 300, 480, 730, 830, 1045r/min
Spindle stroke	450mm
Hoist
Max.single line hoisting capacity	1600kg
Single line lifting speed	1.06, 0.67, 0.32m/s
Wirerope caliber	13mm
Wirerope cubic measure	35m
Hug floodgate caliber	254mm
Hug folldgate belt width	50mm
Distance between drill and hole	230mm
Mud pump
Type	Horizontal single urn twin-action
Displacement	170L/min
Maximum pressure	1.5Mpa
Work pressure	0.7Mpa
Power
Diesle engine	S1105 18HP
Electric motor	Y160M—4 11KW
