APPLICATIONS
SPS600 water source drilling machine is mainly used to drill and explore hydrologic water hole within 600 meters.It’s applicable to earth,terrane and gravel.The machine is propelled by means of mechanical transmission and advanced through driller moving activated by the turning of turntable.It xonsists of main hoist and secondary hoist.Its drill tower is joist framework with`A`structure or tetragonal pipe tower.The drilling machine is dispatched in bulk with strong resolvability.being very convenient for transportation.
MAIN SPECIFICATIONS
1 Drill depth(m): 600
2 Size(mm): φ605
3 Driven drill stem (mm):108×108×8000;108×108×12000
4 Drill pipe within bore (mm):φ73 φ89
5 Rotate speed of turntable (kN.m): 42,75,134
6 Main hoist Single sling hoist strength (kN):35
7 Rating load of big hook (kN): 210
8 Hoist speed of big hook(m/s): 0.15-0.47
9 Pulley block type: 3×3
10Steel wire diameter: φ20-21.5
11Secondary Single sling hoist strength (kN): 15
12Max. hoist strength of single sling (kN): 20
13Permissive hoist speed of single sling (m/s): 0.58
14Steel wire diameter (mm): φ9.8-11
15Drive power (kW): 37
16Mainbody weight (t): 5.5
