APPLICATIONS
RPS3000 Drilling machine for terrestrial heat water is a mechanical driven and start-controlled turntable-drilling machine,It is mainly used to exploit terrestrial heat and underground water,along with to explore and investigate the superficial natural gas,It has following features:great propelling capability;large capacity`s repertory indes;double engine combined with rational match-up ; convenient operation and reliable safety.
MAIN SPECIFICATIONS
1 Drill depth(m) 2500-3500
2 Applicable drill stem(mm) φ89 φ127
3 Drive Power Type: Y315-4 motor 2sets
4 Power: 110kw×2
5 Rotate speed: 1480r/min
6 Turntable Type: ZP-175
7 Rating net load: 272t
8 Max.rotate speed: 350r/min
9 Open diameter: 445mm
10 Transmission ratio: 3.75:1
11 Rotate speed of turntable: clockwise and anticlockwise 33 58 75 131 r/min
12 Rating Max.torque of turntable: 40kN.m
13 Hoist capability of single sling on hoist drum (second floor): 100, 57, 44, 25kN
14 Rotate speed of cathead-like wheel: 90, 158, 203, 356r/min
15 Height of drill tower: 31m
16 load of crane: 130t
17 Weight of whole unit: 18t
