Capillary Stainless Steel Capillary Tube

Name: Capillary Stainless Steel Capillary Tube
Brand: Tello
SKU: 128855703

US$ 1,000 - 3,000 MOQ: 500 Pieces

Key Specifications

Standard:

JIS, AISI, ASTM, GB, DIN, EN

Place of Origin:

Jiangsu, China

Brand Name:

Tello

Nanjing Yuhuatai Tello Stainless Steel Products Factory

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Standard JIS, AISI, ASTM, GB, DIN, EN

Place of Origin Jiangsu, China

Brand Name Tello

Model Number 201,304,316,316L.etc

Type Welded

Steel Grade Other, 200seires,300series

Application industry,construction,decoration.medical equipment.etc

Certification ISO

Welding Line Type Spiral Welded

Thickness 0.1-20mm

Outer Diameter 1-50mm

Specifications

capillary stainless steel capillary tube
1.grade:201,304,316,316l.etc
2.ISO,SGS
3.standard:ASTM A312,GOST,JIS,DIN,BS...

capillary stainless steel capillary tube

Name	Stainless Steel Sanitary Capillary Tube
Standard	ASTM A554, A312, A249, A269 and A270
Material Grade	304,316,201,202, 316L,430
Size Range	1) Outer diameter:≥1mm 2) Wall thickness: ≥0.4mm
Length	6m or as customers' request
Tolerance	a) Outer Diameter: +/-0. 15mm
	b) Thickness: +/- 0.02mm
	c) Length:+/-4. 5mm - 0mm
Surface	180G, 320G, 400G Satin / Hairline(Matt Finish, Brush, Dull Finish) 400G, 500G, 600G or 800G Mirror finish
Application	Ornamental tubes, Decoration construction, upholstery, industry instruments
Test	Squash test, Extended test, Water pressure test, Crystal rot test, Heat treatment, NDT
Chemical Composition of Material	Composition Material	201	202	304	316	430
	C	≤0.15	≤0.15	≤0.08	≤0.08	≤0.12
	Si	≤1.00	≤1.00	≤1.00	≤1.00	≤1.00
	Mn	5.5-7.5	7.5-10	≤2.00	≤2.00	≤1.00
	P	≤0.06	≤0.06	≤0.045	≤0.045	≤0.040
	S	≤0.03	≤0.03	≤0.030	≤0.030	≤0.030
	Cr	16-18	17-19	18-20	16-18	16-18
	Ni	3.5-5.5	4-6	8-10.5	10-14
	Mo				2.0-3.0
Mechanical Property	Material Item		201	202	304	316
	Tensile Strength		≥535	≥520	≥520	≥520
	Yield Strength		≥245	≥205	≥205	≥205
	Extension		≥30%	≥30%	≥35%	≥35%
	Hardness (HV)		<253	<253	<200	<200
