Home > Instruments & Meters > Meter for Electricity > Multimeter > 2016 New Arrival High Quality Digital LCD Display Ohmmeter AC DC Testing VC97 Multimeter

2016 New Arrival High Quality Digital LCD Display Ohmmeter AC DC Testing VC97 Multimeter

Name: 2016 New Arrival High Quality Digital LCD Display Ohmmeter AC DC Testing VC97 Multimeter
Brand: lanho
SKU: 128837233
Availability: InStock

Shenzhen Lanho Technology Co., Ltd.

2016 New Arrival High Quality Digital LCD Display Ohmmeter AC DC Testing VC97 Multimeter thumbnail-1

2016 New Arrival High Quality Digital LCD Display Ohmmeter AC DC Testing VC97 Multimeter photo-1

US$ 10 - 20 MOQ: 50 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

lanho

Model Number:

DL561

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name lanho

Model Number DL561

Features:

1. New type holster, streamline design;
2. Large LCD makes the reading clearly;
3. Strong antimagnetic and anti-jamming performance;
4. Full function protection,;
5. Unit symbol display, very easy to reading;
6. Relative value, frequency/duty cycle measuring, data hold.

7. Built-in Buzz.

8. Safety Compliance: CAT II 1000 V over voltage standards.

Technical data:

Basic function	Range	Basic accuracy
DCV	400mV/4V/40V/400V/1000V	±(0.5%+4)
ACV	4V/40V/400V/750V	±(0.8%+6)
DCA	400uA/4000uA/40mA/400mA/20A	±(1.0%+5)
ACA	400uA/4000uA/40mA/400mA/20A	±(1.5%+5)
Resistance	400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ	±(0.8%+1)
Capacitance	4nF/40nF/ 400nF/4uF/40uF/200uF	±(3.5%+8)
Frequency	100Hz/1kHz/10kHz/100kHz/1MHz/30MHz	±(0.5%+4)
Centigrade temperature	-40℃~1000℃	±(0.8%+4)

Special function	VC97
Diode test	Yes
hFE test	Yes
Continuity test	Approx. less than 30Ω±10Ω
Low battery indication	Approx less than 2.4V
Duty cycle measuring	Yes
Data hold	Yes
Auto power off	Approx.15minutes
Function protect	Yes
Input impendence	10 MΩ
Sampling rate	3 times/s
AC frequency response	40-400Hz
Operation way	Manual or auto range
Max. display	4000
LCD size	65 x 41mm (2.5 inch x 1.6 inch)
Battery	3V AAA×2 (not included)
Power dissipation	Quiescent current approx. 2mA

General characteristic:

Color	Body: dark grey, holster: orange (pantone No.:1495V)
Weight	290g(including battery)
Meter size	185×93×35 mm
Standard accessory	Test leads, battery, manual, TP01 temperature probe
