220mm HD DVB-S2 receiver model: U2C K1
Support: Biss, Multi CAS, Network sharing(IKS), WIFI/GPRS/3G Dongle, OTT, IPTV, WEBTV etc.
Main Features:
1.Fully SD/HD DVB-S2/S compliant,support full HD 1080p
2.Support SD/HD MPEG2 and MPEG4 H.264
3.SCPC & MCPC receivable from C/Ku band satellites
4.DiSEqC 1.0/1.1/1.2 and USALS supported
5.Universal LNB, NIT search support
6.Auto and manually scan all available TV and radio channels
7.Support software upgrade over OTA
8.Powerful and highly effective 7-day EPG function
9.Multi-language menu,subtitle and audio output supported
10.USB 2.0 for PVR,TIMESHIFT,software upgrade and media files playback
11.Support aspect ratio 16:9, 4:3
12.Support parental lock, local time and Teletext
13.Easy to use and attractive menu
14.Support WIFI/GPRS dongle
15.Conditonal Access
16.Up to 6000 channels
17.USB WIFI/GPRS/3G function
Tuner
Input Frequency 950~2150MHz
Loop Out Frequency 950~2150 MHz
Input Level -65~-25dBm
Input Impedance 75
LNB Power 13V/18V/OFF
Demultiplexer
Standard:ISO/IEC 13818-1
Input Max.Bit Stream Rate:Max. 80Mbit/s @ MPEG2,Max. 60Mbit/s @ H.264/AVC
Processor&Memory
CPU K1
Flash Memory 64Mbits
SDRAM 1024Mbits CPU Frequency 400MHz Dual-Core
Powerful Multimedia Features
Photo: JPEG,BMP,PNG
Audio: WMA,MP3,AAC (wma,mp3,m4a)
Video: MPEG1,MPEG2,H264 avi.mpg.dat.vob.div.mov.mkv.mjpeg.ts.trp
NTFS,FAT32,FAT16
JPEG/Audio combo playback
Channel Decoding
Satellite Receiver Standard:DVB-S/S2 SCPC/MCPC compatible
FEC:1/2,2/3,3/4,5/6,7/8 Automatic
Reed Solomon:204,188,t=8
Symbol Rate:2M~44.9M
Video Decording Standard:MPEG-2 MP@ML, H.264,SD&HD
transport stream decoding
Aspect Ratio:4:3,16:9
Audio Decoding
Standard:MPEG Layer 1&2, MP3
Output Mode:Left/Right channel,stereo
Sampling Frequency:32,44.1,48KHz
Peripheral Interface
Indicators: Power, signal lock
IR Receiver: 38KHz
USB2.0
LED display HDMI 1.3 with HDCP
Loop through output: IEC-type, connector, single tuner
SPDIF
10/100M Ethernet
RGB/CVBS/L/R UART
Smart card
Power input Spec.: AC 90-240V,50/60Hz 15W Max
