Google Android 4.4 DVB T2 OTT+FTA Hybrid Combo Digital Receiver TV Box
What is the details of our product?
Product Description | ||
| GDH3-T2 is a quad core HD Android Hybrid Box Android 4.4.2 operating system H.264 1080p Video encoding H.264/H.265 decoding up to 4K×2K 30fps | ||
| Basic parameters | ||
| System | SoC: Allwinner H3 | |
| CPU: ARM Quad Cortex-A7 up to 1.5GHz | ||
| GPU: Mali-450 | ||
| DRAM: DDR3 1GB (512MB Optional) | ||
| Flash: Nand Flash8GB( Nand/EMMC 4GB,8GB,16GB,32GB Optional) | ||
| OS:Android4.4.2 | ||
| Network | RJ45 Interface 10M/100M adaptive | |
| Build in Wi-Fi 2.4GHz/5GHz 802.11a/b/g/n(2.4GHz, 5GHz Optional ) | ||
| Bluetooth 4.0 ( Optional ) | ||
| Support most external 3G/4G USB dongle(Optional) | ||
| Tuner | Tuner+DEMO: MXL608+AVL6762 | |
| Frequency Range: (VHF)174~230MHz, (UHF)474~858MHz | ||
| Input Level: -80~-20dBm | ||
| Input impedance: 75Ω | ||
| I/O | ||
| RF | RF IN, RF OUT, IEC-connector | |
| Video Output | HDMI, AV | |
| Audio Output | Optical | |
| Network | RJ45, Buildin Wi-Fi antenna | |
| Peripheral Interface | USB2.0 x2, SD card slot, CA card slot | |
| Power Interface | DC 12V | |
| Other Interface | Front panel: IR receiver, LED indicator Rear panel: IR IN |
|
| Media | ||
| Video | Decoder: H.265 decoding up to 4K×2K 30fps H.264 HP L5.1 up to 4K×2K 30fps SVC, MVC, VC-1/WMV, AVS, WebM, RMVB, MPEG1/2/4, MJPEG, H.263, DivX 3/4/5, Xvid, Real Video, VP6/8 |
|
| Format: MKV, TS, M2TS, MOV, MP4, RM, RMVB, AVI, MPG, MPEG, DAT, VOB, FLV etc. | ||
| Audio | Decoder: MPEG 1/2/2.5, Audio Layer 1/2/3, WMA Version 4/4.1/7/8/9, WMA Pro, LPCM, PCM, Vorbis, Flac, ALAC, APE, AAC-LC/HEAAC/HE-AAC v2, Real Audio(AC-3 Optional ) |
|
| Format: MP3, WMA, WAV, OGG, M4A, MP4, AAC, APE, FLAC, ALAC, MPEG, MP1, MP2, MPA etc. | ||
| Subtitle Format | SMI, SRT, SSA, ASS,SUB, SUB+IDX, ISO Navigation | |
| Photo Format | HD JPEG/BMP/GIF/PNG/TIFF | |
| Features | ||
| Digital TV | Fully compliant with HD DVB-T2/DVB-T, 7 days EPG, USB PVR, Timeshift, Program playback, Timing playing | |
| CAS | Conax CA (Optional), Patch, BISS, CCCAM, NEWCAM, GSCAM, MGCAM | |
| 4K | H.264/H.265 decoding up to 4Kx2K@30fps, Support 4Kx2K max resolution output | |
| Network Streaming | HTML5, RTSP, HLS, Smooth streaming | |
| Multi-screen interactive | Miracast, DLNA and Airplay | |
| System Upgrading | Upgrading via USB disk or SD card, internet | |
| Local Media Playback | Video/Audio/Picture | |
| External Storage | USB storage, SD card max to 32GB (FAT32/NTFS) | |
| Games | Android 2D/3D games | |
| APP | Facebook, YouTube, Skype, Google play etc. | |
| Other parameters | ||
| Input Voltage | DC IN 12V/1A | |
| Power Consumption | 6W Max | |
| Operation Temperature | 0~40℃, Humidity<95% | |
| Physical characteristics | Size: 140mm*120mm*25mm | |
| Weight: 326g | ||
| Material: plastic+aluminum | ||
| Proposed Accessory | Remote control and Battery, User manual, Power adapter, AV cable, HDMI cable | |
What's the difference between our and other supplier?
As the competiton becomes more and more fiercely,some supplier sacrifice the quality of product in order to make the price much lower, but it will be against customer's interests.We can not promise that our price is lowest, but we believe quality of every single product is the cornerstone a company.
FAQ
Q: 1. How to get the samples?
A: You have to pay the charge of delivery and samples cost first by wester nunion then we deliver the samples by DHL, EMS or UPS. but the charge of sample could be deduct from Order.
Q: 2. Is it possible to customize the design and software?
A: Absolutely yes.
Q: 3.How long it will take to deliver the mass production?
A: It will take 30 days after we receive your 30% deposit.
Q:4. How to repair the receiver if it damaged?
A: We offer more 0.3% receiver for backup.
Q:5. Is it possible to visit your factory?
A: Welcome to china to visit our factory.
What's about our Company?
SHENZHEN GOODVB ELECTRONICS CO.,LTD. is a comprehensive enterprise integrating R&D, production and sales of digital STB(HD DVB-S2, HD DVB-T2, ATSC, ISDB-T, Android Hybrid TV Box).
We operate in a 5000 m2 factory and have more than200 employees, high advanced standard equipment, a strong R&D focus with a dedicated team that are tertiary qualified in engineering, our experienced management levels have acquired bachelor degree and above.
GOODVB products are provide with CE, FCC, 3C and RoHs certification, our company place strategic importance on the relationship with reknown company like MSTAR, ALI, Sunplus,MTK, Rockchip, Allwineer, ESM, Hynix, HannStar, Innolux, CMO, LG, CPT ect.
GOODVB are commited to our focus areas of customer satisfaction, innovative technologies, qualify assurance, the use of advanced production equipment and strict production management.
Our principle is quality first, customer orientation, endless service, product excellence, affordable priced fashionable audio&video entertainment product. With over 10 years of experience, we get full progress and development. not only selling in domestically in 30 local provinces, but also exports to Europe , America, Africa, Australia and Middle East, get good feedback from foreign domestic customer.
We are looking forward to establish business relationship with you.
How to contact us?
Send you inquiry Detail in the Blow for free sample, Click "Send " Now !
