Solar Power System/Solar Home System 500W

Name: Solar Power System/Solar Home System 500W
Brand: Tonghua
SKU: 128769105
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

Tonghua

Model Number:

Solar Power System HNTH-500W

Haining Tonghua Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao/Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name Tonghua

Model Number Solar Power System HNTH-500W

Specification Normal

Application Home

Output Voltage (V) AC110/220V

Load Power (W) 1000W

Solar Power (W) 500W - 50KW as your request

Work Time (h) 6 - 8hours per day

Specifications

Solar panel,solar power
CE Certification have approved
high quality with reasonable price
2years guarantee
solar energysaver

Solar Power System/Solar Home System HNTH-500W

Product Description

Solar home system for 500W, from 100W to 50KW solar system are offered by TONGHUA. Welcome any OEM orders.

Specifications

Solar Panel	Max power	500W( 170W×6)
	Converting efficiency	≥ 16% poly-crystalline silicon with 125×125 standard square
	Electrical data	Open circuit voltage	44.5V	Max voltage	35.9V
		Short circuit current	15.36A	Max current	14.22A
	Type and Size	Type A	1 array*3modules in series 2464×1580 mm	Module size	808×1580×35 mm
		Type B	——
	Installation angle	Install at 0°~ 60°from the horizontal
Battery Pack	Rated capacity	300AH	Combined mode	150AH/12V 2 pcs as an array and 2 arrays in parallel
	Rated voltage	24V
	Battery type	Maintenance-free lead-acid	Discharging rate	≤50%
	Ambient temperature	-30°C~+60°C	Weight	250Kg
	Lifetime	5-8 years
Charge/discharge Controller, Input&output	Charge/Discharge controller	Model	CML20
		Size	20A ( 12/24 adaptorable )
		Manufacturer	Phocos
	DC output	12v	4 outlets for 4 pcs DC 12V/11w CFL
		24V	——
	AC output-A 50/60Hz	Inverted output of standard electricity wave	Rated output power 300W for group-adaptive loads e.g.: lights, TV, electrical heaters etc.
	AC output-B 50/60Hz	inverted output of pure electricity wave	Rated output power 300W for geist electrical machines loads e.g.:fridges,electrical fans,water pumps etc.

Performance

Max Output	DC	12V	100W	Rated output(100%)	DC	12V	60W
		24V	——			24V	——
	AC	Standard electricity wave	400W		AC	Standard electricity wave	500W
		Pure electricity wave	400W			Pure electricity wave	400W
Power ability for 50% loads		Available Power for a sunny day’s charge				6—8 hours
		Available power for full battery				25 hours
