Help CenterWireless Load Cell GS201W
Related Products
Unit: mm
Cap/(t) |
0.5 |
1.0 |
2.0 |
3.0 |
4.0 |
5.0 |
6.0 |
7.5~10 |
B |
32 |
32 |
32 |
32 |
36 |
50 |
50 |
50 |
M |
M12×1.75 |
M12×1.75 |
M12×1.75 |
M12×1.75 |
M20×1.5 |
M24×2 |
M24×2 |
M24×2 |
H |
25 |
25 |
25 |
25 |
25 |
24 |
24 |
24 |
Product Characteristics:
GS201W series is special load cell for crane scale. Element material made of alloy steel or stainless steel according to customer’s requirement. High precision, strong overload protection capacity and anti-deflective loading. The load cell with special hook and ring, easy installation.
Circuit Diagram:
Notice:
Do not use the wireless load cell in explosive and unsafe place. The wireless range will be effective when in different weather, the load cell with the indicator in different place, orientation or obstruct from .For charge: according to Li-ion battery. Do not excess discharge.
Technical Parameter:
Rated Load: |
0.5/1/2/3/4/5/7.5/10t |
Wireless Frequency: |
240GHz |
Wireless Distance: |
Min:80m(default)[200m(optional] |
A/D Conversion Rate: |
≥50 times/seconds |
Battery Life: |
≥50 hours |
Sensitivity: |
(2.0±0.1%) m V/V |
Combined Error: |
±0.02% F.S |
Creep Error(30min) : |
±0.02% F.S |
Zero Balance: |
±1% F.S |
Temp. Effect On Zero: |
±0.02% F.S/10°C |
Temp. Effect On Span: |
±0.02% F.S/10°C |
Input Resistance: |
750±5Ω |
Output Resistance: |
702±2Ω |
Insulation Resistance: |
≥5000MΩ |
Operating Temp. Range: |
-30~+70°C |
Maximum Safe Over Load: |
120%F.S |
Ultimate Over Load: |
200%F.S |
Recommend Excitation: |
10~12V DC |
Maximum Excitation: |
15V DC |
Sealing Class: |
IP67/IP68 |
Element Material: |
Alloy Steel, Stainless Steel |
Citation: |
GB/T7551-2008/ OIML R60 |
Mode Of Connection: |
Red(Input+),Black(Input-),Green(Output+),White(Output-) |
