Usb to Isolated Rs485 / Rs422 Serial Db9 Male Adapter

Usb to Isolated Rs485 / Rs422 Serial Db9 Male Adapter thumbnail-1
Usb to Isolated Rs485 / Rs422 Serial Db9 Male Adapter thumbnail-2
Usb to Isolated Rs485 / Rs422 Serial Db9 Male Adapter photo-1
Usb to Isolated Rs485 / Rs422 Serial Db9 Male Adapter photo-2
US$ 14.8 - 22 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
HighTek
Model Number:
HU-107
Contact Supplier Request Quote Chat Now
Shenzhen Fangxing Liutong Industrial Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name HighTek
Model Number HU-107

Specifications

usb to isolated rs485 / rs422 serial db9 male adapter
UK FTDI master chip
Lightning and ESD protection
CE/RoHS/FCC approval

usb to isolated rs485 / rs422 serial db9 male adapter details:





Product Description



Performance parameters

1,USBV1.1,1.0,2.0 Standard,RS-485,RS-422 TIA/EIA Standard

2,USB Signal: VCC,DATA+,DATA-,GND,FG

3,RS-485 Signal:T/R+,T/R-,GND

4,RS-422Signal:TXD+,TXD-,RXD+,RXD-,GND

5,Working mode: asynchronous working,point-to-point or point-to-multipoint 2 wires (half duplex) 4 wires (full duplex)

6,Direction control:Adopt the technology which automatically controls the data-flow

direction,automatically distinguish and control the data-transmission direction.

7,Transmission rate :300-921600bps, Automatically detect the serial port signal rate

8,Load capability:Support point-to-multipoint transmission. Each converter can connect 32 RS-422 or RS-485 interface equipment.

9,Transmission distance: RS-485/422 port:1.2km (921600bps-300bps).USB port : No more than 5 meters.

10,Interface protection :600W lightning strike and surge protection and ±15KV ESD protection

11,Interface form :USB port: A type male interface. RS-485/422 port: 5-pin connection pole.

12,Signal Indication:3 Pilot Lamps for Power(PWR),Send(TXD) and Receive (RXD)

13,Transmission media:twisted-pair cable or shielded cable.

14,Dimensions:62mmx33mmx19mm

15,Working environment: -40°C to 85°C, relative humidity 5% to 95%.

16,Windows95/98/2000/XP/Vista,IMAG supported.



Connector and signal

RS-485/RS-422 data output & connector and bay-line distribution



Connection pole

Data Output

RS-422 Full-Duplex

RS-485 Half-Duplex

1

T/R+

Send (A+)

RS-485 (A+)

2

T/R-

Send (B-)

RS-485 (B-)

3

RXD+

Receive(A+)

N/C

4

RXD-

Receive(B-)

N/C

5

GND

Ground Wire

Ground Wire



Communication sketch map

USB to RS-422 conversion

1. RS-422 point-to-point 4 wires full-duplex

usb to isolated rs485 / rs422 serial db9 male adapter

2. RS-422 point-to-multipoint 4 wires full-duplex

usb to isolated rs485 / rs422 serial db9 male adapter

USB to RS-485 conversion

1. RS-485 point-to-point 2 wires half-duplex

usb to isolated rs485 / rs422 serial db9 male adapter

2. RS-485 point-to-multipoint 2 wires half-duplex

usb to isolated rs485 / rs422 serial db9 male adapter







usb to isolated rs485 / rs422 serial db9 male adapterusb to isolated rs485 / rs422 serial db9 male adapterusb to isolated rs485 / rs422 serial db9 male adapter



Company Information

usb to isolated rs485 / rs422 serial db9 male adapter

usb to isolated rs485 / rs422 serial db9 male adapter



Certifications

usb to isolated rs485 / rs422 serial db9 male adapter



Packaging & Shipping

usb to isolated rs485 / rs422 serial db9 male adapterusb to isolated rs485 / rs422 serial db9 male adapter



FAQ

Q1: Can you provide OEM service?

Yes, we work on OEM orders.which means design, packing solution,etc will depend on your requests; and your logo will be customized on our products.

Q2: What information should i let you know if i want to get a quotation?

1.Which products are your need?

2.package

3.Quiantitles



Q3: WHY US?

1.The only recommended brand of interface converter by CCTV;

2.Established in 2000, there are 8 branch companies all over China;

3.More than 20 years’ manufacturing in communication filed and more than 15-year customization experience;

4.With professional management, R&D, manufacturing, QC and service team, we are always ready to provide perfect products and service for you;

5.Always the selection of Telefonaktiebolaget LM Ericsson, Huawei, Wachovia Corporation, Foxconn, Motorola, OKI, CNPC, Sinopec and China Mobile since the first cooperation between us.
