Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > Passive Usb to Serial Db9 Ttl Converter

Passive Usb to Serial Db9 Ttl Converter

Name: Passive Usb to Serial Db9 Ttl Converter
Brand: HighTek
SKU: 128745209
Availability: InStock

Passive Usb to Serial Db9 Ttl Converter thumbnail-1

Passive Usb to Serial Db9 Ttl Converter photo-1

US$ 12.5 - 20.5 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

HighTek

Model Number:

HU-08

Contact Supplier Request Quote Chat Now

Shenzhen Fangxing Liutong Industrial Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name HighTek

Model Number HU-08

Specifications

passive usb to serial db9 ttl converter
No external power supply
Point to point communications
300-921600bps transfer speed

passive usb to serial db9 ttl converter details:

Product Description

HighTek HU-08 is a universal USB / TTL converter, no external power supply, compatible with USB, TTL standard, the ability to single-ended USB signals into TTL signals, TTL side through the terminal connections. Converter with zero delay automatic transceiver conversion, unique I / O circuit automatically controls the data flow direction, without any handshaking signals (RTS, DTR like), etc. without the jumper settings to achieve TTL mode conversion, plug purposes. Ensure that it meets all existing communications software and interface hardware.

HighTek HU-08 interface converter for point to point communications to provide reliable connectivity, data communication speed 300-921600bps, with a power indicator and data traffic lights, supports communication with a USB to TTL conversion.

Performance Parameters

1, Standard: comply with USB1.1 1.0, standard, backward compatible with USB2.0, compatible TTLTIA / EIA standards

2, USB signals: VCC, ATA-, DATA +, GND, FG

3, TTL signals: TXD RXD GND

4, Working mode: asynchronous, point communication

5, the direction control: automatic data flow control technology automatically determine and control the direction of data transfer

6, baud rate :300-921600bps automatically detect the serial signal rate

7, load capacity: support point each converter allows to connect a TTL interface devices

8, the transmission distance: TTL side five meters, USB port not more than 5 m

9, Interface Type: USB Type A connector male end, TTL side 5Pin Terminal

10, the signal indication: three signal lights Power (PWR) transmit (TXD) Receive (RXD)

11, the transmission media: twisted pair or shielded cable
