Integrative Filtration System With Sand Filter Pool Equipment Swimming Pool Water Pump

Usage: Spa baths, swimming pools, water treatment facilities
Power:Electric
Standard or Nonstandard: Standard
Fuel: electricity
Horsepower: 2.0-3.0hp
Weight: 16-.00-24.00kg
Port size: 6.66cm
Type: pump for circulation and filtration
Voltage/Hz: 220V~240V/50Hz
Maximum flow: 465~550L/min

Characteristics <<<

High-performance pump body design.
2 "inlet and outlet for highering and performance and lowering noise.
Capacitor running Item for energy-saving, the best choice for low noise.
Thermal overload protector inside ensures the motor safety and prolongs the motors service life.
The model name with Ⅱ means the motor are two speed(2900rpm / 1450rpm), without Ⅱ means single speed.
The model name with E means the joining between the pump body and pump cover is a clamp, without letter E, are bolts&nuts.

Applications<<<

Suitable for spa baths, swimming pools, water treatment facilities.

Ornamental pools and other liquid circulation system circulation and filtration.

Working conditions <<<

Liquid temperature from + 5 ℃ ~ + 60 ℃

Ambient temperature up to 50 ℃

Maximum working pressure: 2.5bar

Motor <<<

2-pole induction motor

Single-phase motors: 220-240V / 50Hz

Single-phase motor with thermal protector from TI

Capacitor inset

Protection IPX5 , Air cool motor are moisture, proof and low temperature.

Continuous duty.

Installation structure<<<

Performance curve<<<

Technical parameters <<<

Our company are mainly SWIMMING POOL EQUIPMENT MANUFACTURE in new generation intelligent pool equipment and accessories as INTEGRATIVE WATER FILTER,SPA and SAUNA PRODUCTS ,now we have own brand FUSSEN and AQUATECHNIQUE. having 30 years' considerable experience in this area.

To ensure product quality to meet clients' demands, we manufacture AQUATECHNIQUE pool equipment in accordance with international standards and strict process flows. Furthermore, we are continually studying and improving new pool products to improve our competitiveness, meet fierce market competition and create the most valuable products for customers.

we sincerely invite clients from at home and abroad to join us and create a bright future together.
