1500kg Ecomomic Narrow Aisle Forklift Side Loading Truck for Sale

1500kg Ecomomic Narrow Aisle Forklift Side Loading Truck for Sale thumbnail-1
1500kg Ecomomic Narrow Aisle Forklift Side Loading Truck for Sale thumbnail-2
1500kg Ecomomic Narrow Aisle Forklift Side Loading Truck for Sale thumbnail-3
1500kg Ecomomic Narrow Aisle Forklift Side Loading Truck for Sale photo-1
1500kg Ecomomic Narrow Aisle Forklift Side Loading Truck for Sale photo-2
1500kg Ecomomic Narrow Aisle Forklift Side Loading Truck for Sale photo-3
US$ 10,000 - 30,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
Noelift
Contact Supplier Request Quote Chat Now
Hangzhou Noelift Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Zhejiang, China
Brand Name Noelift
Model Number TD15
Type Powered Pallet Truck
Power Souce AC Motor
Rated Loading Capacity 1500kg
Max. Lifting Height 7200mm
Min. Lifting Height 3000mm
Fork Length 850mm
Fork Width 100mm
Overall Dimensions 2450mmx1830mmx2104mm
Certification CE,GOST, ISO9001
After-sales Service Provided Overseas third-party support available

Specifications

1.5t side loading reach truck
1, Curtis controller
2, Polyurethane solid tyres;
3,Oil-way stop Valve
4,CHEAPER



Product Description

 1.5t side loading reach truck



TD Series with AC driving motor, Rated load capacity: 1500kg,2000kg, Max. lift height: 7200mm, it's popular in every industries;
1. Safety device for neutral position to increase the safety of forklift;
2. High strength frame to protect the operator;
3. Oil-way stop Valve,to protect the operator and goods;
4. AC electric controller with multiple automatic safety protection settings, to reduce the operation accident by misoperation;
5. Inching capacity, the forklift can finish the extremely adjustment during moving.

Product Pictures

1.5ton side loading reach truck

1500kg ecomomic narrow aisle forklift side loading truck for sale1500kg ecomomic narrow aisle forklift side loading truck for sale1500kg ecomomic narrow aisle forklift side loading truck for sale1500kg ecomomic narrow aisle forklift side loading truck for sale



  Product Parameter

Description Model No.
TD15-30
TD25-30
Rated Capacity (KG)
1500
2500
Operate Type
Stand-on
Stand-on
Max. Lifting Height (MM)
3000
3000
Min. Turning Radius (MM)
2422
2572
Min. Stacking Aisle-- mm (1000*1000 Pallet)
2622
2772
Max Travel Speed km/h -laden/unladen
6.0/7.0
6.0/7.0
Load center MM
500
500
Fork Dimensions -L/W/T---mm
850*100*35
920*100*45
Lifting Speed (MM/S)-laden/unladen
120/270
120/270
Overall Length (MM)
2450
2580
Overall Width (MM)
1830
2000
Height-Overhead guard--mm
2250
2330
Height---Mast Lowered (MM)
2104
2094
Height-Mast Extended w/ Load-Backrest -mm
3885
3875
Height--Free Lift --mm
100
100
Outrigger Height ---mm
415
415
Tilt Angle---- Upward/Downward--deg.
3/5
3/5
Fork Spread Range (MM)
247-973
247-1072
Reach Stroke
1050
1065
Min Ground Clearance--mm
84
88
Wheel Type
Polyurethane Solid Tyre
Driving Wheel (MM)
Φ343×108
Φ343×120
Balance Wheel (MM)
Φ180×76
Φ204×80
Front Wheel (MM)
Φ267×114
Φ267×114
Swivel Caster Wheel---mm
Φ267×76
Φ267×76
Battery V/AH-Domestic BRAND
48V /300 AH
48V/400 AH
Service Brake
Electromagnetic
Parking Brake
Electromagnetic
Charger-Intelligent
48V /40 A
48 V/50 A
Driving Motor (KW)
5.5 (AC)
5.5(AC)
Lifting Motor (KW)
6.3
7.5
