China Made 1.5t Electric Reach Stacker Price With Curtis Controller

China Made 1.5t Electric Reach Stacker Price With Curtis Controller thumbnail-1
China Made 1.5t Electric Reach Stacker Price With Curtis Controller photo-1
US$ 5,000 - 50,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
Noelift
Contact Supplier Request Quote Chat Now
Hangzhou Noelift Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Zhejiang, China
Brand Name Noelift
Model Number TF15,TF20,TF25
Type Powered Pallet Truck
Power Souce AC Motor
Rated Loading Capacity 1500kg, 2000kg, 2500kg
Max. Lifting Height 7500mm
Min. Lifting Height 3000mm
Fork Length 1070mm
Fork Width 100mm
Overall Dimensions 2450mm*1258mm*2100mm
Certification CE,GOST, ISO9001
After-sales Service Provided Overseas third-party support available

Specifications

1.5t electric reach stacker
1,Safety Device for neutral position
2,High Strength frame,
3,Oil-way stop Valve
4,CHEAPER

China made 1.5t Electric Reach Stacker price with Curtis controller

Product Description

 48V Electric Reach Truck
TF Series with AC driving motor, Rated load capacity: 1500kg,2000kg,2500kg, lift height: 7200mm, it's popular in every industries;
1. Safety Device for neutral position to increase the safety of forklift;
2. High Strength frame to protect the operator;
3. Oil-way stop Valve,to protect the operator and goods;
4. AC electric controller with multiple automatic safety protection settings, to reduce the operation accident by misoperation;
5. Inching capacity, the forklift can finish the extremely adjustment during moving;





Product Parameter



F- Electric reach truck 48V



1

Description

Electric reach truck

2

Model

TF15-30

TF20-30

TF25-30

3

Load capacity Kg

1500

2000

2500

4

Load center   mm

500

500

500

5

Max. lifting height mm

3000

3000

3000

6

Tilting angle (forward- backward) deg

3/5

3/5

3/5

7

Wheel type

Polyurethane solid tire

8

Mast forwarding length mm

560

675

675

9

Fork size(LxWxT)mm

1070x100x35

1070x122x40

1070x122x40

10

Fork spread   mm

220-740

265-900

265-900

11

Overall length(with forks) mm

2240

2450

2450

12

Overall width   mm

1098

1258

1258

13

Overall height mast closed   mm

2100

2100

2100

14

Overall height fork raised(with backrest) mm

3900

3900

3900

15

Overhead guard height mm

2320

2320

2320

16

Outside turning radius  mm

1615

1965

1965

17

Min. intersecting aisle(1000*1000pallet)mm

2608

2879

2879

18

Max. walking speeds km/h

7.5/8.5

7.0/8.0

7.0/8.0

19

Lifting speeds (Loaded/ Unloaded) mm/s

117/243

110/243

110/243

20

Grade abitity %

≤10

≤10

≤10

21

Total weight( with battery)   Kg

2300

2600

2600

22

Driving wheel mm

Φ343*108

Φ343*108

Φ343*108

23

Front wheel mm

Φ267*114

Φ267*114

Φ267*114

24

Balance wheel mm

Φ180*76

Φ180*76

Φ180*76

25

Ground clearance mm

80

80

80

26

Service brake

mechanical

27

Parking brake

mechanical

28

Battery  V/Ah

48/300

48/400

48/400

29

Charger   V/A

48/40

48/50

48/50

30

Driving motor Kw

5.5(AC)

5.5(AC)

5.5(AC)

31

Lifting motor Kw

6.3

7.5

7.5

32

Control system

Curtis



product picture

 China made 1.5t Electric Reach Stacker price with Curtis controller            China made 1.5t Electric Reach Stacker price with Curtis controller

China made 1.5t Electric Reach Stacker price with Curtis controllerChina made 1.5t Electric Reach Stacker price with Curtis controllerChina made 1.5t Electric Reach Stacker price with Curtis controller

Our Service

1. One-stop solution service.



2. Customized-service all accepted



3. customer service is in time.



4. free maintence for 1 year.



Any questions please contact us directly.

Noelift provide you with the most professional service in time !
