Rear Axle For TricycleMOQ: 100pcs aa SAMPLE is available)
Main Market: Indoesnia, Kenya and Other country.
We are one leading Three wheel motorcycle & spare parts supplier in China, can offer kinds of Products with high quality and good price. each month, we will send 400 pieces rear axle to Indonesia, we have cooperate with them for more than 5 years.
1. Axle Tube Material:60x4 seamless steel pipe.
2. Total Length: 1160mm
3. 220mm wheel hub, 4 holes
4. steel plate seat: 840mm
5 Use For : Tricycle
6 MOQ: 100pcs ( Sample is available)
7 Payment: By T/T, L/C
8Delivery time: within 20days after receiving deposit or according to quantity.
The technical requirement of rear axle as below:
1.the driving ratio: plain type: high gear 35/14x36/30,AUG Augmentation type:35/14x45/21
2.the max input torque: 300N.m, the max rotating speed: 3000r/min
3.each parts should be agility,Reliable and don't be clampingstagnation when running.
4.the max load bearing: 7000N.
5. Surface treatment: The painting, spurts models or the baking varnish, the request surface not leaks the paint, escapes the paint, flaws and so on flow marking .
6.Welds reliably reliable, the welded joint is smooth, does not allow to leak welds, the faulty soldered joint, does not fuse, scar lump, and so on burning through flaw.
7.all quality shoule be suitable for SLJG08-01.
8.Hydraulic oil capacity is 850ml-900ml.
9.rocker arm shaft should be locate in front horizontal direction.
10.the length of rocker arm shaft is 83mm( SL2400125C),match haplopore straight-arm (
SL2400126a).
11.rear axle welding accessories : steel plate Support
12. the request of adjusting yoke lifting lug is @13, hole shoule be locate in brake Edge.
13.drive shaft: common drive shaft 820mm-38-50X20-20.
14.the length of shift wire drawing is 1280mm.
15.axle tube material: @60x4 seamless steel pipe.
16.Has not poured the common difference size limit deviation
is CB/TL804-0 execute.
This rear axle is use for three wheel motorcycle, cargo tricycle, motor tricycle, electric tricycle.
.
