Comfortable Operation 2.5ton Electric Reach Truck 48VTF

Comfortable Operation 2.5ton Electric Reach Truck 48VTF thumbnail-1
Comfortable Operation 2.5ton Electric Reach Truck 48VTF photo-1
US$ 6,000 - 60,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
NOELIFT
Contact Supplier Request Quote Chat Now
Hangzhou Noelift Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Zhejiang, China
Brand Name NOELIFT
Model Number TF25
Type Powered Pallet Truck
Power Souce AC Motor
Rated Loading Capacity 2500KG
Max. Lifting Height 3000MM
Min. Lifting Height 3000mm
Fork Length 1070mm
Fork Width 100mm
Overall Dimensions 2450x1258x2100mm (LxWxT)
Certification CE
After-sales Service Provided Overseas third-party support available

Specifications

2.5t electric reach truck
1. adopt optimum design, have solid mast and wide vision
2.hydraulic turning,frlexible and reliable



Product Description

2.5ton 48V Electric Reach Track TF series

1, Narrow Chassis suit for narrow asiles.

2, 7.2M lifting height is no problem.
3, Wide vision mast, soft and comfortable design.

TF Series with AC driving motor, Rated load capacity: 2500kg, lift height: 7200mm, it's popular in every industries;
1. Safety Device for neutral position to increase the safety of forklift;
2. High Strength frame to protect the operator;
3. Oil-way stop Valve,to protect the operator and goods;
4. AC electric controller with multiple automatic safety protection settings, to reduce the operation accident by misoperation;
5. Inching capacity, the forklift can finish the extremely adjustment during moving;



Product Picture

comfortable operation 2.5ton electric reach truck 48VTFcomfortable operation 2.5ton electric reach truck 48VTFcomfortable operation 2.5ton electric reach truck 48VTF



Product Parameter

Description

Electric reach truck-TF(48V)

Model

TF15-30

TF20-30

TF25-30

Load capacity  Kg

1500

2000

2500

Load center   mm

500

500

500

Max. lifting height  mm

3000

3000

3000

Wheel type

Polyurethane solid tire

Fork size(LxWxT)mm

1070x100x35

1070x122x40

1070x122x40

Overall length(with forks)  mm

2240

2450

2450

Overall width    mm

1098

1258

1258

Overall height mast closed   mm

2100

2100

2100

Overall height fork raised(with backrest)  mm

3900

3900

3900

Overhead guard height  mm

2320

2320

2320

Outside turning radius   mm

1615

1965

1965

Total weight( with battery)   Kg

2300

2600

2600

Battery   V/Ah

48/300

48/400

48/400

Charger   V/A

48/40

48/50

48/50

Driving motor  Kw

5.5(AC)

5.5(AC)

5.5(AC)

Lifting motor  Kw

6.3

7.5

7.5
