Home > Manufacturing & Processing Machinery > Building Material Making Machinery > Pipe Making Machine > 450mm HDPE Pipe Extrusion Line

450mm HDPE Pipe Extrusion Line

Name: 450mm HDPE Pipe Extrusion Line
Brand: Xingda
SKU: 128633767
Availability: InStock

450mm HDPE Pipe Extrusion Line thumbnail-1

US$ 15,000 - 600,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Type:

Pipe Production Line

Pipe Material:

Contact Supplier Request Quote Chat Now

Zhangjiagang Xingda Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Pipe Production Line

Pipe Material PE

Application Drain Pipe

Production Capacity 150-1500kg/h

Place of Origin Jiangsu, China

Brand Name Xingda

Model Number XD

Voltage 220V,380V, 400V

Power(W) 85-1150kw

Dimension(L*W*H) 40*2.8*3.0m

Weight 12000-40000kg

Certification CE

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

450mm HDPE pipe extrusion line

Process flow

Raw material + additive → mixing → vacuum feeder → hopper dryer → single screw extruder → marking line extruder → mould and calibrator → vacuum calibration tank → cooling tank → haul off machine → printer → cutting machine → pipe storage shelve

Main technical parameter

Model	PE-16/63	PE-20/110	PE-50/160	PE-75/250	PE-110/315	PE-200/450	PE-315/630	PE-400/800
Pipe diameter	16-63mm	20-110mm	50-160mm	75-250mm	110-315mm	200-450mm	315-630mm	400-800mm
Max output	150kg/h	200kg/h	300kg/h	350kg/h	400kg/h	500kg/h	850kg/h	850kg/h
Extrusion speed	1-15m/min	1.2-12m/min	0.6-8m/min	0.5-4m/min	0.4-3.7m/min	0.3-3m/min	0.2-2m/min	0.1-1 m/min
Extruder model	SJ-65/30	SJ-65/33	SJ-75/33	SJ-75/33	SJ-75/33	SJ-90/33	SJ-120/33	SJ-120/33
Installed power	85kw	110kw	125kw	180kw	260kw	325kw	480kw	600kw
Center height	1000mm	1000mm	1000mm	1000mm	1100mm	1100mm	1200mm	1300mm
Line length	35m	38m	38m	40m	42m	52 m	60m	68m

Please feel free to contact us for more information. Additionally, it is worth noting that, it will be more advantageous if you told the diameter and more details of the pipes you are going to produce when sending your messages.
