Help CenterSpraying Robot Arm Machine for Any Shape of Materials
Related Products
-
Cabinet Door Spraying Painting MachineUS$ 26,000 - 29,000MOQ: 1 Set -
Wood Spray Painting MachineUS$ 26,000 - 29,000MOQ: 1 Set
-
Door Spraying Machine /spray Painting MachineUS$ 26,000 - 29,000MOQ: 1 Set
-
Cabinet Door / Door Automatic Spraying MachineUS$ 26,000 - 29,000MOQ: 1 Set
-
MDF / Wood Door Sparying MachineUS$ 26,000 - 29,000MOQ: 1 Set
Specifications
Continuing of a variety of products*Paint type:UV/PU/PE/AC and water based paint
Spraying robot arm machine for any shape of materials JX2050-A
Description:
1.The entire series including the Robot Arm, Rotating Supply Platform,
Spaying and Control System and Oil Supply System.
2.Adopted Japan ASAHI-AGB40 automatic spraying guns.
3.Display Panel can be translated in English or as per your request
language.
4.Different kinds of installation, such as vertical, inclined and
hanging saves the spraying space and cut the cost.
5.Can be widely equipped with exterior equipment.
6.Action Radius=2050mm, Max Speed=2500m/s.
7.Integrated equipment guarantee: 1year (except spraying guns and
diaphragm pump!)
Technical parameters
Items |
Specifications |
||||
Model |
JX2050-A |
||||
Freedom of motion |
6Shaft |
||||
Drive style |
Holoaxial AC Servormotor +Absolute value coder |
||||
Placement style |
Standing or hoisting |
||||
Max Action Range |
Arm |
J1 |
Involution |
360° |
|
J2 |
Nether Action Angle |
180° |
|||
J3 |
Upper Action Angle |
+5°-163° |
|||
Wrist |
J4 |
Rotation 1 |
±260° |
||
J5 |
Action Angle |
±140° |
|||
J6 |
Rotation 2 |
±260° |
|||
Accepted Inertia Moment |
Arm |
J1 |
Involution |
34.1/N.M |
|
J2 |
Nether Action Moment |
34.1/N.M |
|||
J3 |
Upper Action Moment |
9.8/N.M |
|||
Wrist |
J4 |
Rotation 1 |
0.97/kg. m² |
||
J5 |
Action Moment |
0.4/kg. m² |
|||
J6 |
Rotation 2 |
0.1/kg. m² |
|||
Max Speed |
2.0M/S |
||||
Place overlap precision |
±0.5mm |
||||
Max Vertical Distance |
2767mm |
||||
Max Vertical Distance |
2035mm |
||||
Rated Load |
10KG(spraying guns included) |
||||
Temperature Application |
0°-45° |
||||
Humidity |
20-85%RH without Frost |
||||
Display Panel |
40Words,12Rows,4.7″No Backlight LCD |
||||
Power |
3Phase:AC200V(+10%-15%)5060HZ(-2%- +2%) |
||||
Weight |
370KG |
||||
