Door Spraying painting Equipment
(JXUV-DAS-1300)
Application:
Applied for continuing spray the surface of glass-steel door,plastic-steel door,aluminium alloy door,timber door,cabinet door,etc
|
1. Suit for continuing surface spraying according to the heteromorphosis work piecessuch,such as plastic-steel door,glass-steel door,aluminium alloy door,timber door,cabinet door and glass. 2. Five-axis CNC machine painting structures, paint spraying speed, the gun can be flexible rotation angles, fully realized personification spray way. 3. It is a kind of humanoid operation, automatic control, repeatable programming, can be perform a variety of spraying work in the three dimensional space. 4. This is suitable for many varieties flexible manufacturing. It has a important role for stability and improve product painting quality, production efficiency, improve the labor intensity and the rapid upgrading of the product. 5. Saving operation time, easy to operation. 6. this machine is suit for continuing surface spraying according to the heteropmorphosis workpiece,such as plastic-steel door,aluminium alloy door,timber oor, cabinet door and glass. 7. Machine configuration automatically rotating structure, rotary table has two tables, wooden doors after the completion of the painting will automatically rotate to the formation of the flow-trough opetaions, Can achieve continuous production, covers an area of conservation, saving operation time.
| ||
Model |
JXUV-DAS-1300 |
|
Overall Dimensions (mm) |
4200*2200*1800 |
|
Total Power (KW) |
3.47 |
|
Effective Processing Width (mm) |
300—1000 |
|
Effective Processing Length (mm) |
600—2500 |
|
Effective Processing Thickness (mm) |
10 — 50 |
|
Oil-supply Way |
Diaphragm pump |
|
Air Pressure (Map) |
0.4-0.6 |
|
Servo System (KW) |
Japan Yaskawa moter,0.85 0.75 0.37 |
|
PLC |
PANASONIC FP-X C6OR |
|
Spraying Gun Brand |
Japan ANEST IWATA |
|
Spraying Gun caliber (mm) |
0.37 |
|
Quantity of Spraying Gun |
2 |
|
Conveying (complete) speed (min/pic) |
1~5 |
|
Convey Type |
Rotary Type |
|
Paint Type |
PU,UV,NC,AC,water-based paints |
|
Machine Weight (kg) |
2600kg |
|
CERTIFICATION OF QUALITY :
Package
wooden standard carton is suitable for the export and long transportation,free fumigation.
Payment
We usually accept T/T, payment terms : 30% TT deposit, the balance before shipping.
Shipment
Air,sea and express transportation all are available,we have good cooperations with them ,this saves your shipping cost and guarantee your goods safe, if your own forwarder in China can help you to handle the export ,we can accept the factory price(EXW.),
We arrange the local shipment,which’s easy for you to control the transportation cost.
Warranty
- 1 years warranty for the machines.
- Any warranty shipping cost to us is responsible by buyer
FAQ
What is the curtain coating machine for wood floor ,Furniture warranty?
Warranty: Warranty is valid for 12 months in the hypothesis of machinery use for an 8-hour
working shift. Warranty does not cover parts subject to normal wear or damaged by improper
use, incident or negligence of the Buyer or by reasons external to normal use (i.e. change in the
power net, caused by thunderstorm, etc.) Transport costs and labour are excluded.
What about the UV coating machine for wood floor working size?
Usually 300mm . Also It can produce as clients requests.
What is the minimum quantity for order?
One set for order.
Do you have stock product to sell?
Maybe , It’s depend on which machine ,you like?
Do you inspect the finished products?
Yes, Each step of production products will be camed out inspection by QC department
before shipping.
How do you ship the finished products?
As the machines is too big , so usually it is shipping by Sea
What’s the Payment term?
Payment term: 30% TT deposit , the balance before shipment.
What’s the delivery time?
Within 25 days after get the payment
Why choose LINZE?
1,Professional:We are professional in woodworking machinery field for more than 10 years.
2,Excellent:Our machines get great reputation and produce nice quality product for customers all over the world.
3,Economial:We offer the good price with great quality because we do high-volume production manufacturer.
How to contact me?
More details please contact : Alice Xia
Skype ID: alicexia568
email : alice (at )
Company name : Jixingyuan Technology Joint-stock Co., Ltd.
Add.: No.18, Yongxing North Road, Luohe Economic and Technological
Development Zone , Huai Nan city, AnHui Province,China
TEL.: 0086 554 2915218 | F: 0086 554 2915218
Mobile:0086 13309641539(whatsapp and wechat are available)
