2012 Hot Superlink Cat5e Network Cable
US$ 0.1 - 1
MOQ: 10 Kilometers
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
SUPERLINK
Model Number:
network cable
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hot Sell Superlink Cat5 Network CableUS$ 0.1 - 1MOQ: 10 Kilometers -
Factory Cat 6 UTP Lan Cable NETWORK CABLEUS$ 0.1 - 1MOQ: 30 Kilometers
-
Lan Cable Network Cable Utp Cat5eUS$ 0.1 - 1MOQ: 10000 Pieces
-
CAT5 Network Cable 24AWG FTPUS$ 0.1 - 1MOQ: 10 Kilometers
-
Good Quality Cat3 Utp Network Cable Lan CableUS$ 0.1 - 1MOQ: 10 Kilometers
Place of Origin
Zhejiang, China
Brand Name
SUPERLINK
Model Number
network cable
Conductor Material
Other, CU/CCA
Insulation Material
Other, PE/FPE
Jacket
Other, PE/PVC
Number of Conductors
8
Application
For use in communication and signal control systems
Specifications
2012 hot superlink cat5e network cable(1)UL ETL CE ROhS
(2)Factory price
(3)Quick delivery
4))OEM is ok
2012 hot superlink cat5e network cable
cat5e
| 1) Construction | |||
| Center Conductor: | 24 AWG BC/CCA | ||
| Dielectric: | 0.90mm PE | ||
| Shield: | PET+Al Foil+0.5mmCCS | ||
| Jacket: | 5.8mm PVC | ||
| Nom. Thick: | 0.55mm | ||
| 2) Characteristics | |||
| Temperature Rating | -20°C to 60°C | ||
| Dielectric Breakdown: | 2500V | ||
| DC Resistance/Unbalance: | 28.6Ω/1000 Max/5% Max | ||
| Characteristics Impedance: | 100Ω | ||
| 3) Other Electric Performance | ||||
| Frequency | Attenuation | Return loss | Pair to Pair | |
| (MHz) | (dB/100m) | (dB/100m) | ||
| NEXT | ELFEXT | |||
| (dB/100m) | (dB/100m) | |||
| 0.77 | 1.8 | NA | 70 | 69 |
| 1 | 2 | 20 | 68.3 | 66.8 |
| 4 | 4 | 23 | 59.3 | 54.7 |
| 8 | 5.8 | 24.5 | 54.8 | 48.7 |
| 10 | 6.5 | 25 | 53.3 | 46.8 |
| 16 | 8.2 | 25 | 50.3 | 42.9 |
| 20 | 9.2 | 25 | 48.8 | 40.7 |
| 25 | 10.4 | 24.3 | 47.3 | 38.8 |
| 31.25 | 11.7 | 23.6 | 45.9 | 36.9 |
| 62.5 | 17 | 21.5 | 41.4 | 30.8 |
| 100 | 22 | 20.1 | 38.3 | 26.8 |
| 155 | 28.1 | 18.8 | 35.5 | 22.9 |
| 200 | 32.4 | 18 | 33.8 | 20.7 |
| 300 | 41 | 16.8 | 32.3 | 17.2 |
| 350 | 44.9 | 16.3 | 30.2 | 15.9 |
REMARK:
We will do the QC test for the goods before delivery .
We will do the QC test for the goods before delivery .
#Coaxial Cables:
1) RG series Coaxial Cable:Rg59, rg6, rg7, rg8, rg11, RG58, rg142, rg174,rg178, rg213, rg214, RG316,etc.
2) JIS series Coaxial Cable:1.5C-2V, 2.5C-2V, 3C-2V, 3C-2VR, 4C-2V, 5C-2V, 7C-2V, 10C-2V, 3D-2V, 5D-2V, 8D-2V, 10D-2V, etc.
3) Vatc series Coaxial Cable:17vatc, 19vatc, 21vatc, 25vatc, kx6a, kx8
4) TRUNK Cable:412, 500, 540
5) LMR SERIES:LMR200, LMR400, LMR600
#Network Cables:
2) JIS series Coaxial Cable:1.5C-2V, 2.5C-2V, 3C-2V, 3C-2VR, 4C-2V, 5C-2V, 7C-2V, 10C-2V, 3D-2V, 5D-2V, 8D-2V, 10D-2V, etc.
3) Vatc series Coaxial Cable:17vatc, 19vatc, 21vatc, 25vatc, kx6a, kx8
4) TRUNK Cable:412, 500, 540
5) LMR SERIES:LMR200, LMR400, LMR600
#Network Cables:
LAN Cable CAT3, LAN Cable CAT5, LAN Cable CAT5e, LAN Cable CAT6, LAN Cable CAT7 BT3002;
#POWER CABLE SPEAKER CABLE:
2*0.75MM 2*1.5MM 2*2.5MM 3*2MM
2*0.75MM 2*1.5MM 2*2.5MM 3*2MM
Combined Cable:Siamese Cables:RG59+2C
# Cable Materials
Al Wire, Al-mg Alloy Wire, Al Alloy wire;
Al Foil, Bonded Al Foil;
Copper Clad Alluminum wire,CCA, CCAM,CCAwire.
PVC film for cable packing
Al Wire, Al-mg Alloy Wire, Al Alloy wire;
Al Foil, Bonded Al Foil;
Copper Clad Alluminum wire,CCA, CCAM,CCAwire.
PVC film for cable packing
