Wood Panel Sanding Machine
(JXR-R-P600)
1. Sander machine designed for the primer sanding behind the paint coating. It can be applied to various planer products, especially the flat carpentry.
2. Sander machine body adopts weld bend steel board , with the advantage of large weight and steady running. After annealing treatment, it is not easy to change shape.
3. Feeding speed is controlled by the imported stepless governor, with stepless speed regulating.
4. Rubber rollers are made of 25SH natural rubber, with high elasticity and can clear away stripes and white edges, with the advantage of high precision and long serving life.
5. Fault indicator lamps are installed on control panels. For example, when the air pressure is insufficient, it will show on the abrasive belts.
6. Device polishing wheel (optional), frequency controlled and height adjustable, will clear away stripes more easily.
7. Sander machine Voltage: 380V, 50Hz.
| Technical Parameters | |
| Model | JXR-R-P600 |
| working width | 600mm |
| feeding speed | 6~38m/min |
| working thickness | 2.5~100mm |
| abrasive belt size | Φ650*1700mm |
| working ppressure | ≥0.55Mpa |
| dust collect speed | 25~30m/s |
| convey power | 1.5kw |
| abrasive belt power | 5.5kw |
| polishing wheel power | 4.4kw |
| total power | 11kw |
| sander machine size | 1300*1000*2000 |
| machine weight | 1600kg |
Running Model:
dust clean machine after sanding machine
1. Wooden standard carton is suitable for the export and long transportation,free fumigation.
2. Air,sea and express transportation all are available,we have good cooperations with them ,this saves your shipping cost and guarantee your goods safe, if your own forwarder in China can help you to handle the export ,we can accept the factory price(EXW.), We arrange the local shipment,which’s easy for you to control the transportation cost.
Shenzhen Jixingyuan Technology Joint-Stock Co., Ltd
Established in 2003, Shenzhen Jixingyuan Technology Joint-Stock Co., Ltd. is engaged in the production, sale and service of UV surface&edge coating equipments, such as Roller coaters, UV curing equipments, Curtain coaters, Spraying equipments, Robot series and so on.
Jixingyuan is currently the fastest growing painting equipmet company in China market. it has a good reputation and ambitious development goals. Also own an exzcellent team, keep learning experience of domestic and oversea. Struggle for becoming the leading enterprice in the field of painting equipment.
