ceramic tile floor cleaning machine

Machine Configuration

1.   Dust Cleaning Machine  special desighed double nylon cleaning brush, collocated with powerful blower, will clean dust with high efficiency. It can collect all the scrub or saw dust into the dust collection machine.

2. The 3MM anti-skidding conveying belt, which is made from imported material, can increase the   frictional force and also effectively prevent short boards of conveying belts from slipping and not working.

3.  Dust Cleaning Machine innovative and beautiful design occupies a small area.

4.  Dust Cleaning Machine's  lifting system adopts elevators with dovetail groove style. The speed reducer raises and down electrically and smoothly, with good stability.

Equipments required to configurate by customers themselves:

1. 50HZ and 380V three-phase power source.

2. A four- head dust collection machine or a dust collection passage.

Technical Parameters

Model

JXRA V-1000

Working width

1000mm

Feeding speed

5~20m/min

Convey power

1.5kw

Brush wheel power

1.5kw

Fan power

0.2kw*4

Total power

3.8kw

Dust Cleaning Machinesize(L*W*H)

2400*1700*1450mm

Dust Cleaning Machine weight

800kg
