Wireless Vehicle Detector for Traffic System Repalce Loop

Wireless Vehicle Detector for Traffic System Repalce Loop thumbnail-1
Wireless Vehicle Detector for Traffic System Repalce Loop photo-1
US$ 99 - 176 MOQ: 10 Sets
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Rosim
Model Number:
WDS-132
Contact Supplier Request Quote Chat Now
Zhongshan Rosim ITS Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ANY CHINESE PORT
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Rosim
Model Number WDS-132
Style Other, CELNDER
Sensor Other, magetic
Technology Other, RF
Special Features Waterproof / Weatherproof

Specifications

aa The ROSIM wireless vehicle detection system contains wireless vehicle detectors and wireless access point. this setup is som

Wireless Vehicle Detector
high accuracy
Impulse compressive >5 ton
communication distance:150m
Easy and fast installing

 ROSIM Wireless Vehicle Detection System





How the Wireless Vehicle Detection System Works:

  • The ROSIM wireless vehicle detection system contains  wireless vehicle detectors and wireless access point. this setup is sometimes complemented by a repeater, or several.
  • First,the wireless vehicle detectors detect vehicles exsitence/driving dirrection/speed,etc.and then send all the data information wirelessly to wireless access point.at last, wireless access point  aggregates these data and report key traffic parameters such as presence ,lane occupancy,  queue length and so on.



ROSIM Wireless Vehicle Detection

  Wireless Vehicle detector





  Wireless Access Point





Replace loops seamlessly



In the past over 5 years, Rosim wireless vehicle detecting products had successfully replaced loops to monitor vehicles and the relative velocity, occupy rate and traffic flow in many projects of artery, freeway and intersection applications, for example in traffic flow monitoring system, red signal and speed enforcement, traffic lights optimization, traffic guide and traveler information systems, adaptive traffic signal control, arterial performance measurement, etc..









Installing the Detectors:

  •  Detectors  are ideally placed in the middle of traffic lanes.
  •  Lanes are bored a circular hole approximately 10cm in diameter and 10cm deep,then detector is dropped in the hole.
  •  The hole is sealed using fast-hardening rement.
  • The entire operation takes around 10 minutes per detector.



 Advantages

  •  Replace loops seamlessly.The same installation position and compatible output signals makes it easily and simply to replace loops in your system directly;
  •  Install fast. It is only almost 6 minutes that is needed to install one wireless vehicle detector in the road, after installation, the traffic control could be released immediately;
  •  Almost no damage to road comparing to inductive loop.There’s no need to cut slots on the road surface and place cables or wires as the installation of loops, but only a tiny hole with the size Φ 120/H 100 mm, which makes WVDs become the most suitable vehicle detecting solution on the city high-way and bridges;
  • Zero mainenance for sensor and road in 10 years.With high standard water proof and anti-press characteristics,  WVD wireless vehicle detector can even be used in the damaged or distorted roads where loops cannot be installed;
  • Higher efficiency and reliability to other detection methods;
  • Work all-weather. Bad weather for example heavy fog, snow and rain makes no difference;
  •  Easy to maintain. Unlike the loops that are easily to be damaged but difficultly to be repaired, WVD wireless vehicle detector supports firmware updating over the air. No need to re-cut the slots, no more materials needed, and all of what you need is to take almost 10 minutes for the devices wireless updating;
  •  Low operation consuming. Due to the ultra-low power design and battery supply solution, WVD wireless vehicle detector’s consumed power is very lower than any other detectors like loops, video, micro-wave etc. in the market. This appears more and more significantly to our environments.

Applications for ROSIM Wireless Vehicle Detectors:

  • Adaptive traffic signal optimization system
  •  Travel information system
  • Traffic flow monitoring system
  • Red light and speed enforcement
  • Traffic performance measurement
  • Integrated corridor management





Adaptive traffic signal optimization system





 Traffic  and travel information system





Red light and speed enforcement





Integrated corridor management





Maintenance and Support



      Rosim ITS provides our customers high quality wireless vehicle detecting  products and solutions, all the products support wireless updating, which makes it easily to maintain. Also,  Rosim ITS provides 24 hours on-line supports.
