CK6187W wheel hub turning lathe , rim straightening making lathe Quality Assured

FOB Price

USD $10,000 - $22,000 / Set

1 Set(Min.Order)

Product Details

Condition:	New	Type:	Horizontal	CNC or Not:	CNC
Automatic Grade:	Automatic	Max. Swing Diameter:	870mm	Place of Origin:	Shandong, China
Brand Name:	HaiShu	Model Number:	CK6187W	Voltage:	220V/380V
Power(W):	7.5kw	Dimension(LWH):	268017501980mm	Weight:	3500kg
Certification:	CE ISO	After-sales Service Provided:	Engineers available to service machinery overseas

CK6187W Wheel CNC lathe

1.Technical parameters

Project name	Unit	Technical paramaters
Max. turning diameter over the bed	Inch	34”(φ870mm)
Machining diameter of the wheel	Inch	Manual chuck 5"~24" 16"~28”(Optional) Automatic chuck(Optional) 16"~26"
Max. machining length of the workpiece	mm	750
Max. measured depth of the probe	mm	50
Max. machining depth of the tool	mm	50
Machning accuracy		IT6-IT7
Surface roughness	um	Ra0.8~0.1
Main transmission form		Independent spindle; frequency conversion stepless
Range of spindle speed	rpm	150~2000
Main motor power	kw	7.5
Fast-moving feed	mm/min	X - axis:5000 Z - axis:8000
Repeat positioning accuracy	mm	X - axis:0.01 Z - axis:0.015
Standard accessories		4 station electric tool
Repeat positioning accuracy(mm)	mm	0.008
Section of turning tool(mm)	mm	25×25
The size of the machine (L×W×H)	mm	265017502050mm
Net weight of the machine(kg)		3500

2. Main features

1.Achieve the wheel surface profile measurement and data collection and Program Optimization,

2.Automatic precision repair and machining in accordance with the curve of the wheel surface

3.Spindle frequency stepless speed;

4.X / Z axis servo drive;

5.Manual jaw self-centering chuck;

6.Machine guard full protection;

7.Automatic oil lubrication.

3. Uses

1.The machine tool suitable for High-precision turning and repair processing for surface of car wheel.

2.The machine tool has also the function of the general CNC lathes .
