SC/APC Optical Fiber Connector

Name: SC/APC Optical Fiber Connector
Brand: Unikit Optical Technologies
Price: USD $1.6 - 2 / Piece

FOB Price

USD $1.6 - $2 / Piece

100 Pieces(Min.Order)

Product Details

Place of Origin:

Jiangsu, China

Brand Name:

Unikit Optical Technologies

Model Number:

MESC250P-APC

SC/APC Optical Fiber Connector

Description

1. Twin end-face of pre embedded fiber is polised in the factory..

2. Fiber optics is aligned in V-groove through the ceramic ferrule.

3. Side cover design provide complete preservation of the matching liquid.

4. Ceramic ferrule with pre-embedded fiber is polished to APC.

5. Length of the FTTH cable is controllable

6. Simple tooling, easy operation, portable style and reusable design.

Operation video:

/watch?v=n7hUkr5QmJs

/watch?v=EmUgU2Vaquc

Technical specification

Item	Parameter
Cable Scope		3.0 x 2.0 mm Bow-type Drop Cable
Fiber Diameter		125μm ( 652 & 657 )
Coating Diameter		250μm
Mode		SM
Operation Time		about 15s(exclude fiber presetting)
Insertion Loss		≤ 0.25dB(1310nm & 1550nm)
Return Loss		≤ -45dB
Success Rate		>98%
Reusable Times		>10 times
Tensile Strength		>5 N
Tighten Strength of Coating		>10 N
Temperature		-40~+85°C
On-line Tensile Strength Test (20 N)		IL ≤ 0.3dB
Mechanical Durability(500 times)		IL ≤ 0.3dB
Drop Test(4m concrete floor, once each direction, three times total)		IL ≤ 0.3dB
