CC12 speaker box with disco light from Guangzhou factory
- 300 Set / Sets per Month
- Guangzhou Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Guangdong, China | Brand Name: | ZSOUND | Model Number: | CC12 |
Packaging Details
Carton or case
Product Description
CC12 speaker box with disco light from Guangzhou factory
By strict choosing European sophisticated drivers with high transient response, then collocate an excellent frequency
response 44mm HF driver with a low vibrate high sensitivity LF driver. And choose higher tuning frequency & appropriate
volume to get ultra-low group delay and quickly repeat each transient detail effectively. That makes CC12 fit for high acoustic quality applications very well.
The enclosure consists of a 12″ LF driver and a 44mm polymeric membrane HF compression driver. The LF driver’s voice coil is 65mm,
and its speakerframe is made of aluminum. The coverage of the HF horn is 80°, and the angle of trapezoid enclosure at both sides is 20°.
The rotatable horn allows the near-ceiling mounting and aiming easy in the venues with restricted height.
CC12 provides 6 pcs flying tacks used for fixed installations or hanging and angle adjust in touring performance.
The enclosure is configured with a 35mm speaker stands at the bottom.
Feature:
Excellent transient and ideal imlulse image
Coaxial structure,consistentacoustical image andterrific directivity
Applications:
Club
Disco
KTV
TECHNICAL SPECIFICATION | |
FREQUENCY RESPONSE: | 65Hz-18KHz(±3dB) 55Hz--19dB) |
NOMINAL COVERAGE (-6dB): | 80°(H)80°(V) Constant directivity |
SENSITIVITY(@1w/1m): | HF: 108dB SPL LF: 98dB SPL |
POWER RATING (AES): | HF:60W LF:400W |
NOMINAL IMPEDANCE: | HF: 8 Ohm LF: 8 Ohm |
MAXIMUM SPL: | 124dB (continuous)130dB (peak) |
DRIVERS: | LF 1 x 12" (65mm voice coil)woofer; HF 1 x 1.75" (44mm voice coil ) compression driver |
PHYSICAL DATA | |
DIMENSIONS(H x W x D): | 550x 402 x 397mm |
WEIGHT: | 22kg |
CONNECTORS: | 2 x NL4MP Neutrik Speakon connectors |
SPEAKER CABLES: | 1+1- |
MATERIALS: | 18mm,24mm birch plywood |
FINISH: | Black water paint |
GRILLE: | Black epoxy mesh grille with acoustically reticulated foam |
