multi miller CNC550B-1 cnc lathe slant /combination machines
NO. |
Item |
Unit |
Technical parameter |
CNC550B-1×1000 | |||
1 |
Max.rotation diameter on lathe’ body |
mm |
550 |
2 |
piece length |
mm |
1000 |
3 |
Max.turning diameter |
mm |
500 |
4 |
Spindle nose type and code |
mm |
A2-8 |
5 |
Hydraulic chuck |
mm |
Φ300(12”) |
6 |
Front spindle bore taper |
|
1:20 |
7 |
Spindle bore |
mm |
65 |
8 |
Spindle form |
Programmable three gears auto hydraulic speed change |
|
9 |
Spindle frequency control speed range |
rpm |
20-3000 |
10 |
X/Z Rapid traverse |
mm/min |
20000 |
11 |
Main frequency motor power |
kw |
15 |
12 |
X/Z-axis motor max.torque |
N.m |
15 |
13 |
Power specifications |
V |
380±10%. 50Hz±1Hz |
14 |
Turret transfer time |
S |
1.6( horizontal 12) |
15 |
Turret transfer repeat positioning accuracy |
|
0.005" |
16 |
X-axis travel |
mm |
350 |
17 |
Z-axis travel |
mm |
1350 |
18 |
B-axis travel |
mm |
1350 |
19 |
Hydraulic turret form |
|
horizontal 12 stations |
20 |
Tailstock sleeve diameter/ travel |
mm |
80/100 |
21 |
Tailstock tapered bore taper |
Morse |
5# |
22 |
Tailstock form |
|
electric |
23 |
Tailstock sleeve form |
|
Hydraulic driven |
24 |
Knife handle size |
mm |
25×25 |
25 |
Net weight |
kg |
6200 |
26 |
Size(L×W×H) |
mm |
3500×1650×1900 |
main configurations:
1,GSK980TDc or siemens 808D controller, english version
2,Programmable three gears auto hydraulic speed change
3,hydraulic solid chuck
4,horizontal 12 stations hydraulic turret
5,X/Z axis, B axis (tailstock) linear guide
6,Electric tailstock, hydraulic sleeve
7,Turning coolant system
8,Auto lubrication system
9,Whole protection door
10,Voltage:380V/50HZ
11,Auto chip conveyor
GUARANTEE AND AFTER-SALE SERVICES:
1.one year guarantee for whole machine .
2.24-hours technical support by E-mail or telephone
3.User-friendly English software or Russian or Spanish, Users manuals and Detailed Videos/CD
4.Provide extra accessories for the machine
5.Also provide service of make program according to your drawings
6.Customized or special design is OK.
If you are interested in multi miller CNC550B-1 cnc lathe slant /combination machines , welcome to leave a message or send the inquiry to understand the details of machine.
