Item |
Unit |
Specification |
|
Model |
|
CKG1343B |
CKG1350B |
Processing pipe thread diameter range |
mm |
φ270-435 |
φ270-500 |
Maximum workpiece swing diameter over bed |
mm |
1000 |
|
Maximum workpiece swing diameter skateboard |
mm |
610 |
|
Maximum distance between centers |
mm |
1500 |
|
Bed rail width |
mm |
755 |
|
Maximum distance across the dual chuck |
mm |
1940 |
|
Spindle bore diameter |
mm |
φ445 |
φ510 |
Spindle speed mode |
mm |
Tow steps,Frequency stepless |
|
Spindle speed range |
rpm |
Low-grade: 23-120,Highgrade: 65-340 |
|
Main motor power |
KW |
22 |
|
Clamping motor power |
KW |
3 |
|
X/Z axis rapid traverse rate |
m/min |
4/6 |
|
X/Z axis servo motor torque |
Nm |
15/22 |
|
X/Z axis repeat positioning accuracy |
mm |
0.012/0.016 |
|
X-axis maximum stroke |
mm |
450 |
|
Tailstock quill diameter |
mm |
φ140 |
|
Tailstock sleeve taper |
|
MT6 |
|
Tailstock sleeve maximum stroke |
mm |
300 |
|
Cooling pump power |
KW |
0.125 |
|
Automatic lubrication interval time |
min |
12 |
|
)Dimensions (L × W × H) |
mm |
5000×2100×1650 |
|
|
Weight
|
kg |
13000 |
|
three-jaw chuck cnc engraving machine CKG1343B/CKG1350B cnc pipe thread lathe
If you are interested in our products, welcome to leave a message or send the inquiry to understand the details of machine.
