cnc threading machine CKG1313B stainless steel tube polishing machine
Main features:
Bed rail width, heavy weight, good rigidity and stability;
Two gears mechanical transmission, frequency stepless speed regulation.
Standard configuration
1. CNC system :GSK980 ,
2. The spindle two gears frequency conversion speed,
3. Front and rear three-jaw electric chuck,
4. Vertical four-positionelectric turret,
5. With tailstock,
6. Automatic lubrication system,
7. Turning cooling system.
Select Configure
1. CNC system :KND, Siemens, Fanuc,
2. Manual chuck, pneumatic chuck, hydraulic chuck,
3. Horizontal six-position electric turret,
4. The rear bracket, center bracket ,follow tool bracket.
Item |
Unit |
Specification |
CKG1313B | ||
Maximum workpiece swing diameter over bed |
mm |
630 |
Maximum workpiece swing diameter skateboard |
mm |
350 |
Maximum distance between centers |
mm |
1000 |
X-axis maximum stroke |
mm |
300 |
Maximum distance across the dual chuck |
mm |
1450 |
Spindle bore diameter |
mm |
135 |
Spindle speed mode |
|
Spindle 2-gears frequency speed |
Spindle speed range |
r/min |
40-800 |
Bed rail width |
mm |
550 |
Main motor power |
kw |
11 |
X/Z axis servo motor torque |
Nm |
10/15 |
Tailstock quill diameter |
mm |
φ100 |
Tailstock sleeve maximum stroke |
mm |
250 |
Tailstock sleeve taper |
|
MT5 |
X/Z axis rapid traverse rate |
m/min |
4/6 |
X/Z axis repeat positioning accuracy |
mm |
0.012/0.016 |
Dimensions (L × W × H) |
mm |
3600×1650×1810 |
Net weight |
kg |
4200 |
If you are interested in cnc threading machine CKG1313B stainless steel tube polishing machine, welcome to leave a message or send the inquiry to understand the details of machine.
