New Original Azclass Z5 HD update modle 1080p Full HD Satellite Receiver support 3G, IPTV
1.1080P FULL HD DVB-S2
2.CAS, USB,PVR,Ready
3.Free SCAM sharing open channels from Astra ,Nilesat, Hotbird
4.Support Ethernet Sharing, Twin Protocol
5.Support USB Wifi, Youtube, Youporn, Weather forecast, Google map, IPTV, 3G.
| Heatsinking | Yes, Main Chip | ||
| Encrypt | yes | ||
| Video Modulator | yes | ||
| Power Supply | Input 100V ~240V, 50/60Hz | ||
| MPEG4 | High Definition MPEG4 AVC/H.264 HP@L4,MPEG-2 MP@HL/ML | ||
| PAL/NTSC | Automatic PAL/NTSC conversion | ||
| Channels Number | 6000 channels TV and Radio programmable | ||
| Favorites | 8 different favorite groups selection | ||
| OSD Language | English German French Portuguese Spanish Italian Russian Turkish Polish Arabic Farsi | ||
| EPG | Fully support to 7 days Electronic Program Guide(EPG) | ||
| Picture | JPEG,BMP Supported | ||
| OSD Color | 4/8/16-bit OSD with anti-flickering | ||
| Channel Search | Channel search in automatic, manual and network search | ||
| Channel Edit | Various channel editing function(favorite,move,lock,skip,delete,rename,find,sort) | ||
| Parental Ctrl | Parental control for channels | ||
| Easy Menu | Plug and Play installation, with an easy to use Menu System | ||
| SoftUpgrade | Software upgrade through USB | ||
| Time Set | Time set by GMT offset automatic and manual,Summer Time support | ||
| Timer | 5 event timers,off/Once/Daily/Weekly/Monthly Mode | ||
| Subtitle | Subtitle support | ||
| Teletext | VBI insertion for Teletext,CC and WSS | ||
| Save Channel | Automatic save for last channel | ||
| Ethernet | Support RMII interface, Internet Sharing | ||
| RS232S | Support TWIN and Software upgrade | ||
| CAS | Smartcard reader built-in | ||
| 1.Main ChipSet | ||||
| Flash Memory | 64MB Serial Flash | |||
| DDR2 Memory | 1GB | |||
| 2.DVB-S2 Tuner | ||||
| Input Frequency Range | 950MHZ-2150MHZ | |||
| Input Impedance | 75Ω | |||
| RF input Signal LEVEL | -80/-20dBM | |||
| Active Ant Power | 13/18V DC @ 400mA MAX,Overload Protection | |||
| 3.DVB-S2 Channel Decode | ||||
| Demod standard | DVB-S2 Standard | |||
| MPEG Profile Level | MPEG2 SD, MPEG2 HD, H.264/AVC SD, H.264/AVC HD,MPEG4 AVC/H264 | |||
| Demodulation | QPSK,8PSK,16APSK,32APSK | |||
| FFT SIZE | 2K, 8K | |||
| Code Rate | 1/2, 2/3, 3/4, 5/6, 7/8 | |||
| Guard Intervals | 1/4, 1/8, 1/16, 1/32 | |||
| 4.USB Decode | ||||
| PVR | Support | |||
| Media Supporting | USB media player to playback the media in USB flash disk or USB HDD or USB card reader with memory card | |||
| File system | FAT32, NTFS (only support first partition) | |||
| USB | PVR with USB HDD, Time shifting with USB HDD | |||
| 5.Multimedia support format | ||||
| movie | mkv, mp4, avi, flv, f4v, ts, m2ts, mov, 3gp | |||
| music | mp3 | |||
| photo | JPG, BMP | |||
| 6.Video Decode | ||||
| Video Decode | High Definition MPEG4 AVC/H.264 HP@L4,MPEG-2 MP@HL/ML | |||
| Aspect Ratio | Auto, 16:9 Pillar box, 4:3 Pan & Scan, 4:3 Letter Box | |||
| 7.Audio Decode | ||||
| Audio Decode | MPEG1 layer I, MPEG1 layer II, MPEG1 layer III, MPEG2 AAC, MPEG4 HE-AAC | |||
| Sound Mode | LEFT/RIGHT/STEREO/MONO | |||
| Sampling Frequency | 32KHz, 44.1KHz, 48KHz | |||
| 8.Environment | ||||
| Input Voltage | Input 100V ~240V, 50/60Hz | |||
| Consumption | 10W Max | |||
| Temperature | 0℃ to +50℃ | |||
| Humidity | <95% | |||
Contact Information:
MS Ashirley AI
TM ID: cn220022389
Skype: yuwhua03
What's app: +8618692581047
Phone: +8618124620477
Our services:
1. Help you solve technical problems
2. Keep you inform about any updates
3. Provide best software and hardware service, OEM available
4. Guarantee the best quality
5. We provide 1-year warranty for each product from us
Technical support website :
WINSAT Technology Limited. is a high-tech enterprise engaged in the research, development, production and sale of digital set top box and other digital products. Products mainly include DVB-S, DVB-T, DVB-C,DVB-S2 HD Receivers and ISDB-T digital set-top boxes.
We have set up special import and export trading companies in Hong Kong and special production bases and marketing firms in Shenzhen. Due to our mature management experience, business model, industry advantages and corporate credit, we, with six years of responding experience, make full use of our rich human resource and gather lots of excellent engineers and sellers. What’s more, our products have been available in more than 100 countries and regions, such as Northern America, the Middle East, Africa and Europe.
Contact Information:
MS Ashirley AI
Skype: yuwhua03
What's app: +8618692581047
Phone: +8618124620477
1. Help you solve technical problems
2. Keep you inform about any updates
3. Provide best software and hardware service, OEM available
4. Guarantee the best quality
5. We provide 1-year warranty for each product from us
Technical support website :
1, Standard Export Package
2, We will send the package to buyers within 2 days as soon as the payment is received or orders verified.
3, The buyers are responsible for making clearance and paying taxes.
Before making orders, please make sure importing stb is allowed in your local coutries and you can make clearance in time.
WINSAT Technology Limited. is a high-tech enterprise engaged in the research, development, production and sale of digital set top box and other digital products. Products mainly include DVB-S, DVB-T, DVB-C,DVB-S2 HD Receivers and ISDB-T digital set-top boxes.
We have set up special import and export trading companies in Hong Kong and special production bases and marketing firms in Shenzhen. Due to our mature management experience, business model, industry advantages and corporate credit, we, with six years of responding experience, make full use of our rich human resource and gather lots of excellent engineers and sellers. What’s more, our products have been available in more than 100 countries and regions, such as Northern America, the Middle East, Africa and Europe.
